Samsung LH46CKQLBB/ZA Digital Signage Display

The Samsung LH46CKQLBB/ZA Digital Signage Display has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Samsung - Samsung SyncMaster 460UT-2 46" WXGA LCD Monitor - 16:9 - 1366 x 768 - 16.7 Million Colors - 700 Nit - 8 ms - 85 Hz Refresh Rate - DVI - HDMI - VGA - DisplayPort
  • Allows pixels to adjust and accommodate moving scenes and video games with 8 ms response time
  • 16:9 widescreen resolution perfect for watching movies, playing video games and getting on with office work
  • 3,000:1 contrast ratio provides great execution for displaying the darkest black and brightest white
  • View your content easily in well lit areas with 700 Nit brightness
  • Features HDMI input to get connected with the top of the line PCs, Blu-ray players, and cutting edge gaming consoles
  • DisplayPort interface that transmits both audio and video signals through a single connection to deliver versatile performance
  • VESA mount compatibility allows you to mount the display on a wall or with a stand depending on your specific needs
Read More

Need a different version? See all Samsung Parts Accessories

Discontinued Need Assistance?
Add to Quote
Add to My Shopping List Add to Compare
Samsung LH46CKQLBB/ZA Digital Signage Display
Samsung LH46CKQLBB/ZA Digital Signage Display Samsung LH46CKQLBB/ZA Digital Signage Display Samsung LH46CKQLBB/ZA Digital Signage Display Samsung LH46CKQLBB/ZA Digital Signage Display
Samsung LH46CKQLBB/ZA Digital Signage Display
Samsung LH46CKQLBB/ZA Digital Signage Display
Samsung LH46CKQLBB/ZA Digital Signage Display
Samsung LH46CKQLBB/ZA Digital Signage Display
Samsung Parts Accessory Model Overview
Products and parts from Samsung.
Samsung LH46CKQLBB/ZA Digital Signage Display Overview

The Samsung UT series 46 LCD displays feature bezels of just 2.4 mm on the bottom and right, and 4.3 mm on the top and left, for a total of 6.7 mm bezel to bezel enabling video walls are virtually seamless. 460UT-2 offer total solution for video matrix. Simple video matrix installation is possible with embedded video wall feature, supporting max. 10 x 10. The samsung ID stand (MID462-UT2) enables multiple UT series LFDs to be simply stacked just like bricks. The specialised W/M accessary WMN460UTD enables LFDs to be added to and removed from the video matrix already set. White Balance adjustment option enable ensure correctly colored video wall as a whole. Up to 100 LFDs are able to connected as Digital Loop out of HDMI, DVI and Display port with equal picture quality of full HD guaranteed. The RJ45 LAN MDC feature offer the powerful remote controlling with the present RS232C daisy chain MDC.

Technical Information
Number of Screens:
1
Screen Size Class:
46"
Viewable Screen Size:
46"
Screen Mode:
WXGA
Response Time:
8 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Adjustable Display Pivot:
Yes
Display Orientation:
Landscape/Portrait
Mount Type:
Ceiling Mountable
Features:
  • Smart Scheduling
  • Lamp Error Detection
  • Anti-retention
  • Temperature Sensor
  • Picture in Picture
  • Video Wall
  • Button Lock
Video
Maximum Resolution:
1366 x 768
Standard Refresh Rate:
85 Hz
Color Supported:
16.7 Million Colors
Contrast Ratio:
3,000:1
Brightness:
700 Nit
Interfaces/Ports
Network (RJ-45):
Yes
DVI:
Yes
HDMI:
Yes
VGA:
Yes
Component Video:
Yes
Composite Video:
Yes
DisplayPort:
Yes
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
290 W
Standby Power Consumption:
2 W
Off-Mode Power Consumption:
1 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
600 x 400
Height:
22.8"
Width:
40.6"
Depth:
5.1"
Weight (Approximate):
57.98 lb
Miscellaneous
Package Contents:
  • SyncMaster 460UT-2 Widescreen LCD Monitor
  • Quick Setup Guide
  • Warranty Card
  • Application CD
  • D-Sub Cable
  • Power Cord
  • Remote Controller
  • Batteries
  • Panel Bracket
Certifications & Standards:

Safety:

  • UL 60950-1
  • CSA C22.2 No. 60950-1
  • TUV: EN60950-1
  • NEMKO: EN60950-1
  • KC: K60950-1
  • CCC: GB 4943-2001
  • PSB: IEC60950-1
  • GOST: IEC60950-1, EN55022
  • SIQ: IEC60950-1, EN55022
  • PCBC: IEC60590-1, EN55022
  • NOM: NOM-019-SCFI-1993
  • IRAM: IEC60950-1
  • SASO: IEC60950-1

EMC:

  • FCC Part 15, Subpart B class B
  • CE EN55022, EN55024
  • VCCI V-3 (CISPR22)
  • KCC: KN22, KN24
  • BSMI: CNS13438 (CISPR22)
  • C-Tick: AS / NZS3548 (CISPR22)
  • CCC: GB 9254-2008, GB 17625.1-2003
Platform Supported:
PC
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
ENERGY STAR 5.0
Country of Origin:
Mexico
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211902
