Samsung LH46CBQLBB/ZA Digital Signage Display

The Samsung LH46CBQLBB/ZA Digital Signage Display has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Samsung - Samsung 460UT-B 46" WXGA LCD Monitor - 16:9 - 1366 x 768 - 16.7 Million Colors - 450 Nit - 8 ms - 85 Hz Refresh Rate - DVI - HDMI - VGA - DisplayPort

Allows pixels to adjust and accommodate moving scenes and video games with 8 ms response time
16:9 widescreen resolution perfect for watching movies, playing video games and getting on with office work
View your content easily in well lit areas with 450 Nit brightness
Features HDMI input to get connected with the top of the line PCs, Blu-ray players, and cutting edge gaming consoles
DisplayPort interface that transmits both audio and video signals through a single connection to deliver versatile performance

Need a different version? See all Samsung Parts Accessories

Discontinued Need Assistance?

Add to Quote

Samsung LH46CBQLBB/ZA Digital Signage Display

Overview

Samsung Parts Accessory Model Overview

Products and parts from Samsung.

Samsung LH46CBQLBB/ZA Digital Signage Display Overview

The Samsung UT series 460UT-B super narrow bezel display designed to suit various demands. 460UT-B feature bezels of just 2.4 mm on the bottom and right, and 4.3 mm on the top and left, for a total of 6.7 mm bezel to bezel enabling video walls are virtually seamless. Simple video matrix installation is possible with embedded video wall feature, supporting max. 10 x 10. The Samsung ID stand (MID462-UT2) enables multiple UT series LFDs to be simply stacked just like bricks. The specialised W / M accessory WMN460UTD enables LFDs to be added to and removed from the video matrix already set. White Balance adjustment option enable ensure correctly colored video wall as a whole. The built-in computer and MagicInfo software make it easy to control content over LAN / WAN. Up to 100 LFDs are able to connected as Digital Loop out of HDMI, DVI and Display port with equal picture quality of full HD guaranteed. The RJ45 LAN MDC feature offer the powerful remote controlling with the present RS232C daisy chain MDC. Small sensor kit (CY-EBIS) can be put on the edge of product to sense ambient brightness and receive remote controller signal.

Detailed Specs

Technical Information

Number of Screens:

Screen Size Class:

46"

Viewable Screen Size:

46"

Screen Mode:

WXGA

Response Time:

8 ms

Aspect Ratio:

16:9

Horizontal Viewing Angle:

178°

Vertical Viewing Angle:

178°

Adjustable Display Pivot:

Yes

Display Orientation:

Landscape/Portrait

Mount Type:

Wall Mountable
Ceiling Mountable

Features:

Lamp Error Detection
Anti-retention
Temperature Sensor
Picture in Picture
Video Wall
Button Lock

Video

Maximum Resolution:

1366 x 768

Standard Refresh Rate:

85 Hz

Color Supported:

16.7 Million Colors

Contrast Ratio:

4,500:1

Brightness:

450 Nit

Audio

Speakers:

Yes

Interfaces/Ports

Network (RJ-45):

Yes

DVI:

Yes

HDMI:

Yes

VGA:

Yes

Composite Video:

Yes

DisplayPort:

Yes

Built-in Devices

Built-in Devices:

Speaker

Power Description

Input Voltage:

110 V AC
220 V AC

Operating Power Consumption:

205 W

Standby Power Consumption:

2 W

Off-Mode Power Consumption:

1 W

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

600 x 400

Height:

22.8"

Width:

40.4"

Depth:

5.1"

Weight (Approximate):

42.55 lb

Miscellaneous

Package Contents:

460UT-B Widescreen LCD Monitor
Quick Setup Guide
Warranty Card
Application CD
D-Sub Cable
Power Cord
Remote Controller
Batteries

Certifications & Standards:

Safety:

UL 60950-1
CSA: CSA C22.2 No. 60950-1
TUV: EN60950-1
NEMKO: EN60950-1
KC: K60950-1
CCC: GB 4943-2001
PSB: IEC60950-1
GOST: IEC60950-1, EN55022
SIQ: IEC60950-1, EN55022
PCBC: IEC60590-1, EN55022
NOM: NOM-019-SCFI-1993
IRAM: IEC60950-1
SASO: IEC60950-1

EMC

FCC Part 15, Subpart B class
BCE: EN55022, EN55024
VCCI: V-3 (CISPR22)
KCC: KN22, KN24
BSMI: CNS13438 (CISPR22)
C-Tick: AS / NZS3548 (CISPR22)
CCC: GB 9254-2008, GB 17625.1-2003

Energy Star:

Yes

Environmentally Friendly:

Yes

Environmental Certification:

ENERGY STAR 5.0

Item Numbers

UNSPSC: 43211902
