Samsung LH40MECPLGA/ZA Digital Signage Display

Name: Samsung LH40MECPLGA/ZA Digital Signage Display
Brand: Samsung
SKU: 408372

Part Number: LH40MECPLGA/ZA

Model: Parts

Discontinued Need Assistance?

Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Features

Ultra SlimTV TunerAmbient Light SensorMedia PlayerTemperature SensorPlug and PlayPicture by Picture (PbP)Picture in PictureVideo WallButton LockSmart Scheduling

Processor Type

Cortex A9

Processor Speed

1 GHz

L2 Cache

512 KB

Product Description:

Samsung ME-C Series 40" Edge-Lit LED Display - 40" LCD - Touchscreen Cortex A9 1 GHz - 1 GB DDR3 SDRAM - 1920 x 1080 - Edge LED - 450 Nit - HDMI - USB - DVI - SerialEthernet

Explore all Samsung Parts Accessories

Add to Quote

Samsung LH40MECPLGA/ZA Digital Signage Display

Overview

Samsung Parts Accessory Model Overview

Products and parts from Samsung.

Samsung LH40MECPLGA/ZA Digital Signage Display Overview

Samsung's ME-C Series edge-lit, ultra-slim HD LED commercial displays provide exceptional looking content for businesses. The slim bezel design and 1920 x 1080p full HD resolution with high brightness and contrast on the 40" screen deliver maximum impact messaging. An optional touch overlay offers an interactive experience. And compliance with SMART Signage Platform lowers total cost of ownership.

Detailed Specs

Technical Information

Features:

Ultra Slim
TV Tuner
Ambient Light Sensor
Media Player
Temperature Sensor
Plug and Play
Picture by Picture (PbP)
Picture in Picture
Video Wall
Button Lock
Smart Scheduling

Processor & Chipset

Processor Type:

Cortex A9

Processor Speed:

1 GHz

L2 Cache:

512 KB

Memory

Standard Memory:

1 GB

Memory Technology:

DDR3 SDRAM

Display & Graphics

Screen Size:

40"

Display Screen Type:

LCD

Touchscreen:

Yes

Touchscreen Technology:

Capacitive

Multi-touch Screen:

Yes

Display Resolution:

1920 x 1080

Response Time:

8 ms

Aspect Ratio:

16:9

Horizontal Viewing Angle:

178°

Vertical Viewing Angle:

178°

Backlight Technology:

Edge LED

HDCP Supported:

Yes


Image Formats:

JPEG
PNG

Audio

Audio Formats:

AC3

Sound System:

DTS

Video

Video Formats:

MPEG-1
MPEG-2
H.264/MPEG-4 AVC
VC-1
MPEG

Scan Format:

1080p

Standard Refresh Rate:

60 Hz

Dynamic Contrast Ratio:

5,000:1

Brightness:

450 Nit

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Ethernet

Interfaces/Ports

USB:

Yes

USB Standard:

USB 2.0

DVI:

Yes

VGA:

Yes

HDMI:

Yes

Component Video:

Yes

DisplayPort:

Yes

Network (RJ-45):

Yes

Audio Line In:

Yes

Audio Line Out:

Yes

Serial:

Yes

Software

Operating System:

Linux

Power Description

Input Voltage:

110 V AC
220 V AC

Power Consumption:

110 W

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

200 x 200

Height:

21.2"

Width:

36.3"

Depth:

1.2"

Weight (Approximate):

23.37 lb

Miscellaneous

Package Contents:

ME-C Series 40" Edge-Lit LED Display
Quick start guide
Warranty card
Application CD-ROM
D-Sub cable
Power cable
Remote control
Batteries

Certifications & Standards:

EMC:

FCC (USA): FCC Part 15, Subpart B, Class A
CE (Europe): EN55022, EN55024, VCCI (Japan): V-3 (CISPR22)
KCC (Korea): KN22, KN24
BSMI (Taiwan): CNS13438 (CISPR22)
C-Tick (Australia): AS / NZS3548 (CISPR22)
CCC (China)

Security:

cUL (USA + Canada): UL60065
TUV (Germany): EN60065
CB (Europe): IEC60065 / EN60065
EK (Korea): K60065
CCC (China): GB8898
PSB (Singapore): IEC60065
GOST (Russia) : IEC60065, EN55022
SIQ (Slovenia): IEC60065, EN55022
PCBC (Poland): IEC60065, EN55022
NOM (Mexico): NOM-001-SCFI-1993
IRAM (Argentina) IRAM
SASO (Saudi Arabia): IEC60065

Energy Star:

Yes

Environmentally Friendly:

Yes

Environmental Certification:

ENERGY STAR 6.0

Item Numbers

GTIN: 0887276025520

UPC: 887276025520

EAN: 0887276025520

UNSPSC: 43211902
