Ruckus ICX7450-48P-E2 Network Switch

Ruckus - Ruckus Wireless ICX7450-48P-E Ethernet Switch - Manageable - TAA Compliant - 3 Layer Supported - Modular - Optical Fiber - 1U High - Rack-mountable - Lifetime Limited Warranty
  • Effectively increases available bandwidth on your network
  • Cascade to other network devices through the uplink port to expand your local area network
  • Power Supply power source for dependable power supply
  • Can work as layer 3 routing for scalable network design
  • Rack mounting enables you to organize wires & secure cables for professional installation
  • Management capability provides control over setup and configuration of your network
  • Optimize the performance of business networks with 10 Gigabit Ethernet connectivity
  • Supports optical fiber cable to span longer distances and provided high data transmission rates between servers and network components
Read More
$13,982.88
In Stock
Recommended TrueSupport Coverage (/mo.)

x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device

Only /month
Subtotal ( items)

x
You've just added this product to the cart:

Go To Cart
Add to Quote
Ruckus Parts Accessory Model Overview
Products and Parts from Ruckus.
Ruckus ICX7450-48P-E2 Network Switch Overview
ENTERPRISE STACKABLE SWITCH DELIVERS PREMIUM CAPABILITIES AND ULTIMATE FLEXIBILITY

The Ruckus® ICX® 7450 switch delivers the performance, flexibility, and scalability required for enterprise Gigabit Ethernet (GbE) access deployment. It offers market-leading stacking density with up to 12 switches (576x 1 GbE and 144x 1/10 GbE ports) per stack and combines chassis-level performance with "pay as you grow" scalability of a stackable solution. The mid-market stackable switch is one of the first in its class to offer 40 GbE uplinks, enabling enterprises to dramatically increase their network capacity while using their existing optical wire infrastructure. In addition, the Ruckus ICX 7450 is the industry's first stackable switching solution to leverage the advantages of site-to-site IPsec VPN security to ensure end-to-end data integrity without the need for dedicated encryption appliances.

The modular design of the switch provides three slots for scaling up to 12 1/10 GbE SFP/SFP+ ports, 12 10GBASE-T ports, or up to three 40 GbE QSFP+ ports for uplink or stacking. Organizations can initially deploy 1 GbE or 10 GbE uplink ports and easily upgrade to 40 GbE ports on-demand with a new, high-speed module. As a result, Ruckus ICX 7450 delivers high performance across all ports for flawless support of latency-sensitive applications.

System-level high-availability features, such as dual hot-swappable, load-sharing, and redundant power supplies, and hot-swappable fan trays offer another level of availability for the campus wiring closet, all in a 1 RU form factor.

The switch is an ideal network solution for campus network 1 GbE access or small aggregation deployment with 10 GbE or 40 GbE uplinks to the core. The switch is also suitable for a data center Top-of-Rack (ToR) solution, providing a mix of 1 GbE and 10 GbE server connectivity ports with 10 GbE or 40 GbE uplinks to the data center aggregation or core.

Deployed as a standalone switch, a stack, or a network fabric, organizations reap the benefits of a flexible platform and the assurance that their investments are protected.

FULL POWER SUPPORT FOR NEXT-GENERATION EDGE DEVICES

The Ruckus ICX 7450 can deliver both power and data across network connections, providing a single-cable solution for the latest edge devices. In addition to supporting the Power over Ethernet (PoE/PoE+) standards, the switch also supports Power over HDBaseT (PoH) and IEEE 802.3bt ready ports. This high power standard delivers up to 90 watts per port through a standard Ethernet cable, simplifying the wiring of next-generation Ethernet-connected devices such as large HD displays, video surveillance equipment, and VDI thin terminals. The PoE/PoE+ and PoH capabilities reduce the number of required power receptacles and power adapters while increasing reliability and wiring flexibility. With a 1,500-watt PoE budget per switch (with two power supplies), the Ruckus ICX 7450 24- and 48-port PoE models can supply up to Class 4 PoE+ power (30 watts) to every port and PoH power (90 watts) on eight dedicated ports.

RUCKUS ICX 7450 PRODUCT FAMILY

All Ruckus ICX 7450 models offer three modular slots for interchangeable uplink/stacking modules (one in the front, two in the back), dual power supply slots, dual fan trays, one RJ-45 network management port, one mini USB serial management port, and one USB storage port on the front panel.
Interfaces/Ports
Uplink Port:
Yes
Modular:
Yes
Stack Port:
Yes
Port/Expansion Slot Details:
  • 48 x Gigabit Ethernet PoE+
  • 4 x 10 Gigabit Ethernet Expansion Slot
  • 2 x 40 Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
Optical Fiber
Ethernet Technology:
  • Gigabit Ethernet
  • 10 Gigabit Ethernet
  • 40 Gigabit Ethernet
Network Technology:
  • 1000Base-X
  • 10GBase-X
  • 40GBase-X
I/O Expansions
Number of Total Expansion Slots:
6
Expansion Slot Type:
  • SFP+
  • QSFP+
Number of SFP+ Slots:
4
Network & Communication
Layer Supported:
3
Management & Protocols
Manageable:
Yes
Power Description
Power Source:
Power Supply
Redundant Power Supply Supported:
Yes
Power Consumption:
106 W
Physical Characteristics
Compatible Rack Unit:
1U
Form Factor:
Rack-mountable
Height:
1.7"
Width:
17.3"
Depth:
15.5"
Weight (Approximate):
15.87 lb
Miscellaneous
Package Contents:
  • ICX7450-48P-E Ethernet Switch
  • 1 × 1,000 W AC Power Supply
Environmentally Friendly:
Yes
Environmental Certification:
  • WEEE
  • RoHS-6
TAA Compliant:
Yes
Warranty
Limited Warranty:
Lifetime
Item Numbers
UNSPSC: 43222612
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Ruckus ICX7450-48P-E2 Network Switch is also known as RUC-ICX745048PE2
