Ruckus 901-R710-US00 Access Point

Ruckus ZoneFlex R710 - Wireless ZoneFlex R710 IEEE 802.11ac 1.69 Gbit/s Wireless Access Point - 2.40 GHz, 5 GHz - MIMO Technology - 2 x Network (RJ45) - Gigabit Ethernet - Wall Mountable, Ceiling Mountable
  • 802.11ac Multi-User MIMO (MU-MIMO)
  • Concurrent dual-band (5 GHz/2.4 GHz) support
  • 80 MHz channelization; 256-QAM modulation support; 1733 Mbps PHY rates at 5 GHz
  • 256-QAM support on 2.4GHz
  • Ethernet Port Link Aggregation (LACP)
  • Backward compatible with legacy 802.11 clients
  • 802.3af mode of operation
  • 802.11ac standard Tx Beamforming
  • Space Time Block Coding for increased handset performance
  • Improved Maximum Ratio Combining (MRC) for best-in-class receive sensitivity
  • Low Density Parity Check (LDPC) for increased data
  • throughput at all ranges
  • BeamFlex+ (PD-MRC) improves signal reception of mobile devices
  • Integrated smart antenna with many unique patterns for ultra reliability
  • Unmatched Rx sensitivity down to -104 dBm
  • USB port for hosting Internet-of-Things (IoT) devices such as Bluetooth Low Energy (BLE) smart beacons
  • Either standalone or centrally managed
  • Integrated NAT and DHCP support
  • Multicast IP video streaming support
  • Four software QoS queues per client station
Read More
$1,295.00 Login or call for price
Temporarily out of stock; available to order
Recommended TrueSupport Coverage ($6.67/mo.)
x

Are you sure you don't need TrueSupport?

The average internal IT
cost for device support is over $325 per year!

With TrueSupport you're
covered - and for way less!
  • Hardware Helpdesk Support
  • RMA Repair Facilitation
  • OEM Service Contract Management
  • Premium Phone & Email Support
  • Billed annually per device
$80.00
Only $6.67/month
Subtotal ( items)

Full specifications (PDF)

Industry's highest performing 802.11ac AP
Featuring BeamFlex+ adaptive antenna technology, the ZoneFlex R710 offers a substantial increase in performance and range by optimizing antenna coverage on a per client, per transmission basis. BeamFlex+ additionally mitigates co-channel interference by directing Wi-Fi signals where they are needed instead of towards neighboring access points. The R710's BeamFlex+ adaptive antenna system is also equipped with dual polarization antennas, allowing the access point to adapt to the physical orientation of client devices and maximize uplink performance. With throughput capacities of 800 Mbps (2.4GHz) and 1733 Mbps (5GHz), the ZoneFlex R710 supports the highest available throughput for Wi-Fi clients. 802.11ac Multi-User MIMO (MU-MIMO) support allows the R710 to simultaneously transmit to multiple client devices, drastically improving airtime efficiency, overall throughput, and availability.
Ruckus 901-R710-US00 Overview
DUAL-BAND 4X4:4 802.11AC SMART WI-FI AP

Ruckus' Highest Capacity, Highest Performing Four-Stream 802.11ac AP
The ZoneFlex R710 combines Ruckus patented technologies and best-in-class design with the next generation of 802.11ac features to deliver industry-leading Wi-Fi performance and reliability.

Featuring BeamFlex+ adaptive antenna technology, the ZoneFlex R710 offers a substantial increase in performance and range by optimizing antenna coverage on a per client, per transmission basis. BeamFlex+ additionally mitigates co-channel interference by directing Wi-Fi signals where they are needed instead of towards neighboring access points. The R710's BeamFlex+ adaptive antenna system is also equipped with dual polarization antennas, allowing the access point to adapt to the physical orientation of client devices and maximize uplink performance.

With throughput capacities of 800 Mbps (2.4GHz) and 1733 Mbps (5GHz), the ZoneFlex R710 supports the highest available throughput for Wi-Fi clients. 802.11ac Multi-User MIMO (MU-MIMO) support allows the R710 to simultaneously transmit to multiple client devices, drastically improving airtime efficiency, overall throughput, and availability. The ZoneFlex R710 is backward compatible with all existing Wi-Fi clients, and can function either as a standalone AP or as part of centrally-managed Wireless LAN.

ZoneFlex R710 is purpose-built for high-capacity, high performance and interference-laden environments such as schools, universities, public venues, hotels, and conference centers. The perfect choice for data-intensive streaming multimedia applications, the ZoneFlex R710 delivers picture perfect HD-quality IP video while supporting VoIP and data applications that have stringent quality of service requirements.
Protect Your Product

Full specifications (PDF)

Technical Information
Wireless LAN Standard:
IEEE 802.11ac
Frequency Band:
  • 2.40 GHz
  • 5 GHz
Wireless Transmission Speed:
1.69 Gbit/s
MIMO Technology:
Yes
Interfaces/Ports
Ethernet Technology:
Gigabit Ethernet
Number of Network (RJ-45) Ports:
2
PoE (RJ-45) Port:
No
PoE PD Port:
Yes
VGA:
No
HDMI:
No
USB:
Yes
Powerline:
No
Management Port:
No
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Ceiling Mountable
Height:
2.4"
Width:
8.7"
Depth:
8.7"
Weight (Approximate):
2.43 lb
Miscellaneous
Package Contents:
  • ZoneFlex R710 Dual Band 802.11ac Access Point
  • Adjustable Acoustic Drop Ceiling Bracket
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • WEEE
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0190801045314, 0712155578494, 4943793106046, 7111195875489
UPC: 190801045314, 712155578494
EAN: 0190801045314, 0712155578494, 4943793106046, 7111195875489
UNSPSC: 43222631


The Ruckus 901-R710-US00 is also known as RUC-901R710US00 or 901R710US00 .
