Ruckus 901-R300-US02 Wireless Access Points

Part Number: 901-R300-US02
Model: ZoneFlex R300
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11n
ISM Band
Yes
UNII Band
Yes
ISM Minimum Frequency
2.40 GHz

Product Description:

  Ruckus Wireless ZoneFlex R-300 IEEE 802.11n 300 Mbit/s Wireless Access Point - 1 x Network (RJ-45) - Ethernet, Fast Ethernet, Gigabit Ethernet - Desktop, Wall Mountable, Ceiling Mountable
Explore all Ruckus ZoneFlex R300 Wireless Access Points
Add to Quote
Ruckus 901-R300-US02 Wireless Access Points
Ruckus 901-R300-US02 Wireless Access Points
Ruckus 901-R300-US02 Wireless Access Points
Ruckus 901-R300-US02 Wireless Access Points Ruckus 901-R300-US02 Wireless Access Points Ruckus 901-R300-US02 Wireless Access Points
Full specifications (PDF)

Ruckus ZoneFlex R300 Wireless Access Points Model Overview

The next generation Ruckus ZoneFlex R300 is an entry level 802.11n 2x2:2 dual-band 2.4GHz and 5GHz concurrent access points designed for bandwidth hungry and latency sensitive applications such as Voice and Video over Wi-Fi. These APs boast Ruckus patented adaptive antennas deliver BeamFlex. This technology works in conjunction with Ruckus’ advanced channel optimization to provide industry-leading wireless performance. Unlike any other 802.11n wireless solution in its class, the ZoneFlex R300 combines patented adaptive antenna technology and automatic interference mitigation to deliver consistent, predictable performance at extended ranges with up to an additional 4dB of BeamFlex gain on top of the physical antenna gain and up to 10dB of interference mitigation.
Ruckus 901-R300-US02 Wireless Access Points Overview
The Industry's Best-in-Class Performance at Lowest Cost

The next generation Ruckus ZoneFlex™ R300 is an entry level 802.11n 2x2:2 dual-band 2.4GHz and 5GHz concurrent access points designed for bandwidth hungry and latency sensitive applications such as Voice and Video over Wi-Fi. These APs boast Ruckus patented adaptive antennas deliver BeamFlex. This technology works in conjunction with Ruckus' advanced channel optimization to provide industry-leading wireless performance. Unlike any other 802.11n wireless solution in its class, the ZoneFlex R300 combines patented adaptive antenna technology and automatic interference mitigation to deliver consistent, predictable performance at extended ranges with up to an additional 4dB of BeamFlex gain on top of the physical antenna gain and up to 10dB of interference mitigation.
Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11n
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.40 GHz
ISM Maximum Frequency:
2.48 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.85 GHz
Antenna Gain:
3 dBi
Wireless Transmission Speed:
300 Mbit/s
Wireless Security:
  • WPA-PSK
  • WPA-TKIP
  • WPA2 AES
  • IEEE 802.11i
  • IEEE 802.1X
  • RADIUS
  • NAT
Features:
  • MIMO Technology
  • Quality of Service (QoS)
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE (RJ-45) Port:
No
PoE PD Port:
Yes
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
No
Management & Protocols
Management:
  • DHCP
  • Web User Interface (HTTP/S)
  • CLI
  • Telnet
  • SSH
  • SNMP v1, 2, 3
  • TR-069 vis FlexMaster
Power Description
Input Voltage:
12 V DC
Physical Characteristics
Form Factor:
  • Desktop
  • Wall Mountable
  • Ceiling Mountable
Height:
1.1"
Width:
5.1"
Depth:
5.1"
Weight (Approximate):
14 oz
Miscellaneous
Certifications & Standards:
  • EN-60601-1-2
IEEE Standards:
  • 802.1x
  • 802.11i
  • 802.11b
  • 802.11g
  • 802.11n
  • 802.11a
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • WEEE
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN: 0015568556470, 0190801045260, 0702685246314, 0728350939312, 0795945997316, 0795954970881
UPC: 015568556470, 190801045260, 702685246314, 728350939312, 795945997316, 795954970881
EAN: 0015568556470, 0190801045260, 0702685246314, 0728350939312, 0795945997316, 0795954970881
UNSPSC: 43222631
