Ruckus 901-7962-WW00 Access Point

Ruckus 901-7982-WW00 Access Point A newer version of this item is available.
It is replaced by the Ruckus 901-7982-WW00 Access Point.
Ruckus ZoneFlex 7962 - Ruckus Wireless ZoneFlex 7962 IEEE 802.11n 600 Mbit/s Wireless Access Point - 2 x Network (RJ-45) - Ethernet, Fast Ethernet, Gigabit Ethernet - PoE Ports - Wall Mountable, Ceiling Mountable
  • When connected to a compatible router or a network switch, this wireless access point lets you enjoy wireless internet connectivity throughout your home or office
  • Build a reliable home or business network with this Wireless Access Point, that features IEEE 802.11n technology and speeds up to 600 Mbit/s
  • Ethernet port provides Ethernet connections for fast data transfer and large file transfers between your access point and wired network
Read More

Need a different version? See all Ruckus ZoneFlex 7962 Access Points

Discontinued See Replacement
Add to Quote
Add to My Shopping List Add to Compare
Ruckus 901-7962-WW00 Access Point
Ruckus 901-7962-WW00 Access Point Ruckus 901-7962-WW00 Access Point Ruckus 901-7962-WW00 Access Point Ruckus 901-7962-WW00 Access Point Ruckus 901-7962-WW00 Access Point Ruckus 901-7962-WW00 Access Point
Ruckus 901-7962-WW00 Access Point
Ruckus 901-7962-WW00 Access Point
Ruckus 901-7962-WW00 Access Point
Ruckus 901-7962-WW00 Access Point
Ruckus 901-7962-WW00 Access Point

Full specifications (PDF)
Ruckus ZoneFlex 7962 Access Point Model Overview
The ZoneFlex 7962 is based on adaptive antenna technology that extends signal range two to four times while minimizing packet loss by constantly routing Wi-Fi transmissions over the highest performing signal paths. It's also the only 802.11n product purpose-built for hotels, schools and enterprises that enables high-definition IPTV, video-ondemand and other video applications while supporting VoIP and data applications for guests and employees. Ideal for multimedia and high-density user environments, the ZoneFlex 7962 can be deployed as a standalone access point or as part of centrally-controlled Smart Wireless LAN with the Ruckus ZoneDirector. Smart Mesh Networking, another unique feature, makes the ZoneFlex 7962 perfect for reliably extending wireless LAN services to areas where cabling Ethernet isn't possible or economical.
Ruckus 901-7962-WW00 Access Point Overview

The Ruckus ZoneFlex 7962, the industry's top performing dualband 802.11n access point with adaptive antenna technology, delivers ultra-high speed, reliable and longest-range connectivity within challenging RF environments.

The ZoneFlex 7962 is based on adaptive antenna technology that extends signal range two to four times while minimizing packet loss by constantly routing Wi-Fi transmissions over the highest performing signal paths.

Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11n
ISM Band:
Yes
UNII Band:
Yes
ISM Minimum Frequency:
2.40 GHz
ISM Maximum Frequency:
2.48 GHz
UNII Minimum Frequency:
5.15 GHz
UNII Maximum Frequency:
5.85 GHz
Antenna Gain:
7 dBi
Antenna Type:
Omnidirectional Antenna
Wireless Transmission Speed:
600 Mbit/s
Wireless Security:
  • WEP
  • WPA-TKIP
  • WPA-PSK
  • WPA2-AES
  • IEEE 802.1x
  • IEEE 802.11i
  • RADIUS
  • Kensington Lock
  • LDAP
Features:
Quality of Service (QoS)
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Number of Network (RJ-45) Ports:
2
Network (RJ-11):
No
PoE (RJ-45) Port:
Yes
VGA:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
No
Management & Protocols
Management:
  • Web Based Management (HTTP/HTTPS)
  • SNMP
  • ZoneDirector
  • TR-069 FlexMaster
  • CLI
  • Telnet
  • IEEE 802.1Q VLAN
Power Description
Input Voltage:
12 V DC
Physical Characteristics
Form Factor:
  • Wall Mountable
  • Ceiling Mountable
Height:
4.9"
Width:
5.7"
Depth:
7.6"
Weight (Approximate):
1.50 lb
Miscellaneous
Certifications & Standards:
  • IEEE 802.11a
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
  • IEEE 802.3
  • IEEE 802.3u
  • IEEE 802.3ab
  • IEEE 802.3af
  • IEEE 802.1x
  • IEEE 802.11i
  • IEEE 802.1Q
  • EN 60601-1-2
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • WEEE
Item Numbers
UNSPSC: 43222631
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Ruckus 901-7962-WW00 Access Point is also known as RUC-9017962WW00
