Ruckus 901-7363-WW00 Wireless Access Points

Name: Ruckus 901-7363-WW00 Wireless Access Points
Brand: Ruckus
SKU: 133600

Part Number: 901-7363-WW00

Model: ZoneFlex 7363

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Wireless LAN Standard

IEEE 802.11n

ISM Band

Yes

UNII Band

Yes

ISM Minimum Frequency

2.40 GHz

Product Description:

Ruckus Wireless ZoneFlex 7363 IEEE 802.11n 300 Mbit/s Wireless Access Point - 3 x Network (RJ-45) - Ethernet, Fast Ethernet, Gigabit Ethernet - PoE Ports - Wall Mountable, Ceiling Mountable

Explore all Ruckus ZoneFlex 7363 Wireless Access Points

Add to Quote

Ruckus 901-7363-WW00 Wireless Access Points

Overview

Full specifications (PDF)

Ruckus ZoneFlex 7363 Wireless Access Points Model Overview

A sleek and low-profile design, the ZoneFlex 7363 was purpose-built for cost-minded enterprises requiring reliable high speed client connectivity. It is ideal for a variety of enterprise and hotspot environments including hotels, schools, retail outlets, branch offices and public venues. Unlike any other 802.11n wireless solution in its class, the ZoneFlex 7363 combines patented adaptive antenna technology and automatic interference mitigation to deliver consistent, predictable performance at extended ranges with 4dBi of signal gain and 10dB of interference rejection. The ZoneFlex 7363 can also be easily deployed using Smart Mesh Networking to extend Wi-Fi services in locations where Ethernet cabling is not available or cost prohibitive.

Ruckus 901-7363-WW00 Wireless Access Points Overview

The Ruckus ZoneFlex 7300 series delivers high-performance and reliable 802.11n wireless networking at the industry's most affordable price point.

Unlike any other 802.11n wireless solution in its class, the ZoneFlex 7300 combines patented dynamic beamforming and automatic interference mitigation to deliver consistent, predictable performance at extended ranges with 4dBi of signal gain and 10dB of interference rejection.

Detailed Specs

Full specifications (PDF)

Technical Information

Wireless LAN Standard:

IEEE 802.11n

ISM Band:

Yes

UNII Band:

Yes

ISM Minimum Frequency:

2.40 GHz

ISM Maximum Frequency:

2.48 GHz

UNII Minimum Frequency:

5.15 GHz

UNII Maximum Frequency:

5.85 GHz

Antenna Gain:

4 dBi

Antenna Type:

High Gain Antenna

Wireless Transmission Speed:

300 Mbit/s

Wireless Security:

WEP
WPA-PSK
WPA-TKIP
WPA2-AES
RADIUS
IEEE 802.11i
IEEE 802.1x
LDAP

Features:

Quality of Service (QoS)

Interfaces/Ports

Ethernet Technology:

Ethernet
Fast Ethernet
Gigabit Ethernet

Number of Network (RJ-45) Ports:

Network (RJ-11):

PoE (RJ-45) Port:

Yes

VGA:

Serial Port:

USB:

Powerline:

Management Port:

Management & Protocols

Management:

Web Based Management (HTTP/HTTPS)
SNMP
FlexMaster
ZoneDirector
Telnet
CLI
IEEE 802.1Q

Power Description

Input Voltage:

12 V DC

Physical Characteristics

Form Factor:

Wall Mountable
Ceiling Mountable

Height:

1.4"

Width:

Depth:

Weight (Approximate):

14 oz

Miscellaneous

Package Contents:

ZoneFlex 7363 Wireless Access Point
Cable Cover

Certifications & Standards:

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
IEEE 802.11n
IEEE 802.3
IEEE 802.3u
IEEE 802.3ab
IEEE 802.3af
IEEE 802.11i
IEEE 802.1x
IEEE 802.1Q
EN-60601-1-2

Environmentally Friendly:

Yes

Environmental Certification:

WEEE
RoHS

Item Numbers

UNSPSC: 43222631
