rf IDEAS RDR-800W1BKB-P Access Control Reader

Part Number: RDR-800W1BKB-P
Model: WAVE ID Plus
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$639.08
In Stock

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Identification Method
Radio-frequency Identification (RFID)Proximity
Application/Usage
HealthcareGovernmentManufacturingEnterpriseIndustryKiosksIndoor
Ingress Protection (IP) Rating
IP67
Connectivity Technology
Wireless

Product Description:

  Access Control Card Reader, rf IDEAS WAVE ID Plus, RF IDeas WAVE ID Plus Keystroke V2 w/ iCLASS ID Surface Mount Black EtherNet/IP PoE Read, Black Healthcare, Government, Manufacturing, Enterprise, Industry, Kiosks, Indoor, Radio-frequency Identification (RFID), Proximity, 13.56 MHzOperating Frequency, Ethernet, Network (RJ-45), USB, Serial
Explore all rf IDEAS WAVE ID Plus Access Control Readers
Add to Quote
rf IDEAS RDR-800W1BKB-P Access Control Reader
rf IDEAS RDR-800W1BKB-P Access Control Reader
rf IDEAS RDR-800W1BKB-P Access Control Reader
rf IDEAS RDR-800W1BKB-P Access Control Reader
rf IDEAS RDR-800W1BKB-P Access Control Reader rf IDEAS RDR-800W1BKB-P Access Control Reader rf IDEAS RDR-800W1BKB-P Access Control Reader rf IDEAS RDR-800W1BKB-P Access Control Reader
Full specifications (PDF)

rf IDEAS WAVE ID Plus Access Control Reader Model Overview

The rf IDEAS WAVE ID® Plus Dual-Frequency Card Reader is the ultimate solution for organizations seeking to streamline access control and credential management. This robust reader supports a variety of card types and configurations, making it an ideal choice for dynamic environments. With its auto-tuning feature, the WAVE ID Plus optimizes performance across different settings and offers user-selectable volume control for alerts. Designed to integrate seamlessly into existing systems, it simplifies login processes, enhancing efficiency while maintaining security.
Key Features
  • Four ID Card Configurations: Two pre-set and all four user definable
  • Auto-Tuning: For optimized performance across various environments
  • User-Selectable Volume Control: Including beeper on/off settings
  • Robust Compatibility: Works with proximity, contactless, and magnetic swipe cards
  • Plug-and-Play Functionality: No software needed for integration

Specifications
  • Model Series: RDR-805x1AKx, RDR-80582AKU, RDR-800x1AKx, RDR-80082AKU, RDR-8X581AKU, RDR-8X582AKU, RDR-8X081AKU, RDR-8X082AKU
  • Operating Frequency: 125/132 kHz and 13.56 MHz
  • Interface: USB
  • Dimensions: 3.6" x 2.1" x 0.7"
  • Weight: 4.0 ounces (113.39g)
  • Housing Color: Black
  • Cable Length: 6' standard; 6" and 16" lengths available
  • Operating Temperature Range: -22° to 150°F
  • Operating Humidity Range: 5% to 95% relative humidity, non-condensing
  • Storage Temperature Range: -40° to 185°F
  • Power Supply: USB self-powered; some RS-232 models require external power source
  • Certifications: FCC, CE Mark, RCM, IC, UL Environmental
rf IDEAS RDR-800W1BKB-P Access Control Reader Overview

WAVE ID® Plus Surface Mount

As our most feature-rich offering, the WAVE ID Plus card readers maximize the value of new and existing ID badges by providing simultaneous processing of contactless and proximity smart cards. This dual-frequency card reader performs at the highest technical standards while serving diverse applications with our signature ease of use. Also available in an SDK compatible model, it can integrate into most software or hardware through the use of the rf IDEAS® Universal Software Developer's Kit (SDK) This multi-technology reader delivers flexibility to any customer, integrator or end user struggling with different card technologies. In use with the rf IDEAS Configuration Utility, the WAVE ID Plus card reader also functions as a comprehensive card analyzer for determining compatible readers.

The WAVE ID Plus Surface Mount reader mounts nearly anywhere and supports improved authentication with nearly all proximity and contactless cards worldwide. The reader comes in four card configurations (two are pre-set and two are user-definable) and mounts easily with two screws on a single gang electrical box. In addition, it features user-selectable volume control with an optional beeper on/off setting

FEATURES

  • Delivers card ID in formats that multiple applications recognize
  • Standard four card configurations (two are pre-set; two are user-definable)
  • Ideal for enrollment into third-party software or for single sign-on integrators
  • User-adjustable beeper volume can be set to high, low or off as appropriate for the work environment
  • 13.56 MHz auto-tuning ensures optimal power transfer to avoid interference
  • For a full list of supported cards types, supported-card-types

BENEFITS

  • Delivers nearly limitless possibilities for user identification and authentication
  • Simultaneously reads proximity and contactless card technologies
  • Customizable to work with any card solution for any size corporation
  • Eliminates error associated with individual identification and manual entry
  • Users can quickly configure reader output to meet their needs
  • Ideal for government, healthcare, manufacturing/industrial and enterprise
Full specifications (PDF)
Technical Information
Identification Method:
  • Radio-frequency Identification (RFID)
  • Proximity
Application/Usage:
  • Healthcare
  • Government
  • Manufacturing
  • Enterprise
  • Industry
  • Kiosks
  • Indoor
Ingress Protection (IP) Rating:
IP67
Connectivity Technology:
Wireless
Network & Communication
Ethernet Technology:
Ethernet
Wireless LAN:
No
Interfaces/Ports
USB:
Yes
Network (RJ-45):
Yes
Serial:
Yes
Power Description
Operating Frequency:
13.56 MHz
Physical Characteristics
Color Family:
Black
Product Color:
Black
Height:
4.3"
Width:
2.5"
Depth:
0.4"
Weight (Approximate):
2.60 oz
Miscellaneous
Package Contents:
  • WAVE ID Plus Keystroke V2 w/ iCLASS ID Surface Mount Black EtherNet/IP PoE Read
  • IP67 Installation Guide
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Item Numbers
UNSPSC: 46171600
