rf IDEAS RDR-80031BKU-V2 Access Control Reader
Full specifications (PDF)
rf IDEAS WAVE ID® Plus Mini Access Control Reader Model Overview
The rf IDEAS WAVE ID® Plus Mini is a compact, dual-frequency card reader designed for identification, authentication and logical-access applications. It supports 125/132 kHz proximity credentials and 13.56 MHz contactless smart cards, including MIFARE® Secure technologies such as DESFire EV1, EV2 and EV3. Four configurable card profiles allow organizations to support multiple credential technologies through a single reader. With USB, USB Virtual COM and RS-232 options, the WAVE ID Plus Mini supports applications such as single sign-on, secure print management, time and attendance, cashless payments and industrial vending.
Key Features
Compact desktop design: Measures only 2.9 inches long, 1.7 inches wide and 0.5 inches high.
Dual-frequency operation: Reads 125/132 kHz proximity credentials and 13.56 MHz contactless smart cards.
Four card configurations: Includes two preset configurations, with all four profiles user-definable.
Multiple operating modes: Supports Keystroke, rf IDEAS SDK, CCID and ASCII configurations.
Flexible connectivity: Available with USB, USB Virtual COM and RS-232 interfaces.
MIFARE Secure support: Supports DESFire EV1, EV2 and EV3, Classic, Plus, Ultralight and Ultralight-C.
Optimized reader performance: Patented 13.56 MHz antenna auto-tuning helps minimize environmental interference.
Adjustable indicators: Includes a quad-state LED and user-selectable beeper volume.
Mobile credential support: Supports compatible credentials through Apple Wallet, Google Wallet and Allegion HCE.
Mounting options: Compatible with Mini Desktop mounting accessories designed to help prevent tampering or removal.
Specifications
Product Series: WAVE ID® Plus Mini
Reader Type: Dual-frequency proximity and contactless card reader
Operating Frequency: 125/132 kHz and 13.56 MHz
Interfaces: USB, USB Virtual COM and RS-232 Serial
Operating Modes: Keystroke, CCID and ASCII
Dimensions: 2.9" L x 1.7" W x 0.5" H (74 x 42 x 13 mm)
Weight: 4.0 oz (113.39 g)
Housing Color: Black
Cable Length: 6' standard; 6" and 16" options available
Indicators: Quad-state LED and adjustable beeper
Power Supply: USB self-powered; select RS-232 models require an external power source
Power Consumption: 65 mA typical, 185 mA maximum
Operating Temperature: -22° to 150°F (-30° to 65°C)
Storage Temperature: -40° to 185°F (-40° to 85°C)
Operating Humidity: 5% to 95% relative humidity, non-condensing
Certifications: FCC, CE Mark, RCM, IC, RoHS and REACH
Compatible Operating Systems: Windows 10 and 11, macOS Monterey and later, Ubuntu Linux 20.04 and later, supported Chromium-based browsers, Android 14 and earlier, and Raspberry Pi
Configuration Tools: rf IDEAS Configuration Utility, Smart Card Manager and Remote Reader Management Tool
Frequently Asked Questions
What card types does the rf IDEAS Wave ID Plus Mini support?
The Wave ID Plus Mini features dual-frequency reader technology that works with nearly every proximity and contactless smart card worldwide. It supports up to four simultaneous card configurations, making it highly flexible for diverse workplace access control needs. This broad compatibility eliminates the need for multiple readers across different card standards.
How does the Wave ID Plus Mini integrate with existing access control systems?
The Wave ID Plus Mini emulates keystrokes and integrates seamlessly with most software and hardware solutions through SDK-compatible models available from us. This flexibility allows you to connect it to your existing access control infrastructure without requiring major system overhauls. Contact us today to discuss integration requirements for your specific setup.
What makes the Wave ID Plus Mini different from other rf IDEAS access control readers?
The Wave ID Plus Mini is the smallest reader in the rf IDEAS Wave ID family while maintaining the most capability as a desktop reader. Its compact size, dual-frequency technology, and support for four simultaneous card configurations make it ideal for space-constrained environments that still require powerful access control functionality.
Is the rf IDEAS Wave ID Plus Mini suitable for warehouse and logistics environments?
Yes, the Wave ID Plus Mini is well-suited for warehouse and logistics operations where access control and inventory management intersect. Its ability to support multiple card types and integrate with various software systems makes it valuable for facilities managing both personnel access and asset tracking. Visit barcodesinc.com to explore how this reader can enhance your warehouse operations.
What connectivity options does the Wave ID Plus Mini offer?
The rf IDEAS Wave ID Plus Mini connects via USB and functions as a keystroke emulator, allowing it to work with standard computer systems and access control software. This USB connectivity ensures reliable communication and simplifies deployment across multiple workstations without requiring specialized hardware interfaces.
Can the Wave ID Plus Mini handle multiple card standards simultaneously?
Yes, the Wave ID Plus Mini supports up to four simultaneous card configurations, allowing it to read and process different card types without requiring manual switching or reconfiguration. This multi-configuration capability makes it an excellent choice for organizations with mixed card deployments or those planning to transition between card standards. Contact us today to learn more about configuring multiple card types for your facility.
