rf IDEAS WAVE ID® Writer Access Control Reader Model Overview
The WAVE ID® Writer is a versatile desktop read/write reader designed for NXP MIFARE® Classic contactless smart cards. It efficiently integrates with existing control systems, allowing users to write to contactless smart cards through easy plug-and-play functionality on a computer. With its Card Manager software and optional SDK, users can customize applications, enhance security with RF data encryption, and utilize unique keys for mutual authentication. The WAVE ID® Writer streamlines workflows by facilitating single sign-on and automating processes across various industries, making it the ideal solution for upgrading to advanced technologies while leveraging existing systems.
Key features:
Easy Interface: Connects via USB with non-keystroking data functionality.
Simple Integration: SDK kit for fast MIFARE product setup with high-level commands.
Security: Mutual authentication and cryptographic data storage features.
Cost-effective: Utilizes a single card to cut down on printing and training costs.
Industry Compliance: Meets ISO standards including ISO 14443 & ISO 15693.
Specifications:
Model Series: RDR-7580AKU
Operating Frequency: 13.56 MHz
Interface: USB (with SDK available)
Physical Characteristics:
Dimensions: 3.4" x 2.0" x 0.6"
Weight: 4.0oz (113.39g)
Housing Color: Black
Cable Length: 6' (with 6" and 16" options)
Indicators: LED (green, amber, red); Adjustable beeper volume
Environmental:
Operating Temperature: -31° to 150°F (-35° to 65°C)
Humidity: 5% to 95% non-condensing
Storage Temperature: -40° to 185°F (-40° to 85°C)
Other:
Certifications: FCC, CE Mark, C-TICK
Compatible OS: Windows XP, 7, 8, 10, Linux, macOS, Android
Card Types: Supports nearly all card types
rf IDEAS RDR-7580AKU Access Control Reader Overview
The AIR ID product line meets a variety of needs in multiple situations. AIR ID products leverage current badge investments and existing control systems while expanding technologies and applications with a single badge solution.
Full specifications (PDF)
