Raytec VAR2-W8-1 Infrared Illuminator

Part Number: VAR2-W8-1
Model: Parts
Add to My Shopping List Add to Compare
$893.33

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Device Supported
Video Surveillance SystemSmart Light SystemLighting Control
Features
Interchangeable LensPlatinum Elite SMT LED TechnologyAdvanced Security SettingHot-spot Reduction Technology (HRT)LED IndicatorGreen TechnologyProgrammableLED IlluminationEven IlluminationAutomatic On/Off
Color Family
Silver
Product Color
Silver

Product Description:

  IR Illuminator, Raytec, VARIO Illuminators, Vario2 w8 White Light with 3 angle options incl. 10,35 & 60 deg 12/24V
Explore all Raytec Parts Accessories
Add to Quote
Raytec VAR2-W8-1 Infrared Illuminator
Raytec VAR2-W8-1 Infrared Illuminator
Raytec VAR2-W8-1 Infrared Illuminator Raytec VAR2-W8-1 Infrared Illuminator
Technical Information
Device Supported:
  • Video Surveillance System
  • Smart Light System
  • Lighting Control
Features:
  • Interchangeable Lens
  • Platinum Elite SMT LED Technology
  • Advanced Security Setting
  • Hot-spot Reduction Technology (HRT)
  • LED Indicator
  • Green Technology
  • Programmable
  • LED Illumination
  • Even Illumination
  • Automatic On/Off
Physical Characteristics
Color Family:
Silver
Product Color:
Silver
Height:
7"
Width:
5"
Depth:
2.6"
Weight (Approximate):
3.60 lb
Miscellaneous
Additional Information:
Illuminator:
  • Total Lumens 3727lm per luminaire
  • Max Distance 180m (591ft)
  • Angle Standard pack includes 10° circular + 35° x 10° (fitted as standard) and 60° x 25°elliptical lenses. Additional optional lenses: 80° x 30°, 120° x 50°
  • Input 12/24V AC/DC
  • Consumption 42W max
  • Number of LEDs 24 Wavelength White-Light
  • Colour Temp 6000K ~
  • Colour Reproduction Index >70
  • Temperature Range -50° to +50°C (-58 to 122°F)
  • Cable Length 2.5m
Integrated Command and Control Technology:

Integrated Standard Features:
  • Power adjust from 20-100%
  • In-built photocell for automatic on/off operation
  • Photocell following output
  • Photocell sensitivity adjust
  • LED status indicator provides status on performance of the unit
  • LED status indicator on/off
  • Disable programming mode
Advanced Features (accessed via VARIO remote control):
  • Timer function (up to 30 mins)
  • Telemetry control
  • Remote Dimming
  • Restore factory default settings
  • Optional PIN to lock in settings and limit access
  • Remote Control can be disabled for improved security
Application/Usage:
Surveillance
Certifications & Standards:
IP66
Country of Origin:
United Kingdom
Item Numbers
UNSPSC: 46171600
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Raytec VAR2-W8-1 Infrared Illuminator is also known as RAY-VAR2W81
