Device Supported:
USB Type C Device
RAM Mount RAM-GDS-CHARGE-V7-USBCU Accessory
Part Number:
RAM-GDS-CHARGE-V7-USBCU
Model:
Parts
RAM Mount Parts Products Model Overview
Products and parts from RAM-Mount.
RAM Mount RAM-GDS-CHARGE-V7-USBCU Accessory Overview
The GDS® Modular Hardwire Charger with Type C cable is the ideal solution for providing power to any GDS® vehicle solution. With the quick disconnect feature, easily connect any USB Type A charging cable. When it comes time to upgrade, avoid any rewiring by simply unplugging the power connector and attaching the new charger components. Compatible with any 5V device with a current requirement of 2.5A or less.
Technical Information
Interfaces/Ports
USB:
Yes
USB Type-C:
Yes
Power Description
Input Voltage:
- 12 V DC
- 24 V DC
Input Voltage Range:
8 V DC - 40 V DC
Output Voltage:
5 V DC
Maximum Output Current:
2.50 A
Physical Characteristics
Weight (Approximate):
6.88 oz
Miscellaneous
Additional Information:
- Input Cable Length: 1.2 Meters overall length including 2 Pole Flat Marine Connector
- Output Cable Length: .2 Meters (w/ included 1M USB Type-C Cable)
- Operating Temperature Range: -10°C to +70°C
- Storage Temperature Range: -40°C to +70°C
- Overvoltage/Load Dump Compliance: Meets SAE J-1113
- Integrated Short Circuit Protection (SCP)
- USB 2.0 BC 1.2 DCP Support
Certifications & Standards:
- FCC
- Industry Canada
- CE
- RCM
- e-Mark
Environmentally Friendly:
Yes
Environmental Compliance:
- Waste Electrical and Electronic Equipment Directive (WEEE)
- Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN:
0793442006838
UPC:
793442006838
EAN:
0793442006838
UNSPSC:
39121006
The RAM Mount RAM-GDS-CHARGE-V7-USBCU Accessory is also known as
RAM-GDS-CHARGE-V7-USBCU
