PowerDsine PD-6506/AC/M

PowerDsine 6500 Series - 6506 (6-Port, 100W Total Power)

The PowerDsine 6500 series sets a new standard for highly secure, remotely-managed and safe-to-use Power over Ethernet Midspans (PoE injectors). The PowerDsine 6500 series comprises 48, 24, 12 and 6-port models, making an even wider range of flexible Power over Ethernet installations possible. The PowerDsine 6500 family allows IP telephones, wireless LAN access points, security network cameras and many other types of data terminals to receive power, along with data, over standard Ethernet cables, leaving network infrastructure completely unaltered. With PoE, data and power flow smoothly and safely over a single LAN cable with no interference.

Technical Information

  • Compatibility:
    • IP Telephones
    • Wireless LAN Access Points
    • Security Network Cameras
  • Input Voltage:
    • 110 V AC
    • 220 V AC
  • Output Power:
    • 15.40 W Per Port
    • 100 W Total
  • Output Voltage: 52 V DC

General Information

  • Product Type: PoE Injector Hub
  • Product Series: 6500
  • Brand Name: PowerDsine
  • Manufacturer: Microsemi Corporation
  • Product Model: 6506
  • Product Name: 6506 Power over Ethernet Midspan

Physical Characteristics

  • Height: 1.8"
  • Width: 17.3"
  • Depth: 10.8"
  • Weight (Approximate): 8.80 lb

Interfaces/Ports

  • Output Ports: 6 x RJ-45 10/100Base-TX

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority:
    • RoHS
    • WEEE
  • Certifications & Standards:
    • IEEE 802.3f Complaint
    • CE
    • UL
    • VCCI
    • CISPR 24
    • cUL
    • EN 60950
    • GS
    • EN55024
    • CISPR 22
    • EN55022 Class B
    • FCC Part 15 B
    • IEEE 802.3f Complaint
    • CE
    • UL
    • VCCI
    • CISPR 24
    • cUL
    • EN 60950
    • GS
    • EN55024
    • CISPR 22
    • EN55022 Class B
    • FCC Part 15 B
  • Compatibility:
    • IP Telephones
    • Wireless LAN Access Points
    • Security Network Cameras
  • Additional Information: Remote SNMPv3 or Web-based management

Power Description

  • Frequency: 47 Hz to 63 Hz
  • Input Current:
    • 2 A @ 110 V AC
    • 1 A @ 220 V AC
  • Input Voltage:
    • 110 V AC
    • 220 V AC
  • Output Power:
    • 15.40 W Per Port
    • 100 W Total
  • Output Voltage: 52 V DC

Warranty

  • Limited Warranty: Lifetime

Full specifications (PDF)



The PowerDsine PD-6506/AC/M is also known as PDS-PD6506ACM or PD6506ACM .
