Planar PXL2430MW Touchscreen

Planar - 24IN WIDE BLACK LED MULTI-TOUCH OPTICAL TOUCH SCREEN WITH USB, ANALOG, DVI-D, HDMI, INTERNAL POWER, SPEAKERS, 0 - 20 TILT
  • The Full HD lcd touchscreen monitor is perfect for point-of-sale, hospitality, and many other retail applications
  • Optical touch screen technology utilizes two line inspecting cameras situated in the side at the top of the screen which constantly monitors the field of view
  • The Full HD screen size with 1920x1080 resolution provides the native display of a Full HD video source without any degradation due to down-sampling technologies
  • The 1,000:1 contrast ratio produces enhanced sharpness and shading accuracy in each picture
  • LED backlight enhances the display performance to deliver an outstanding color range and contrast ratio
  • The 250 Nit brightness gives an exceptionally visible display for clear and consistent on-screen pictures
  • VESA mount compatibility allows you to mount the touch screen on a wall or with a stand depending on your specific needs
Read More
$412.80
Add to Quote
Planar Parts Accessory Model Overview
Products and parts from Planar.
Technical Information
Screen Size Class:
24"
Viewable Screen Size:
24"
Screen Mode:
Full HD
Response Time:
5 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
170°
Vertical Viewing Angle:
160°
Adjustable Display Angle:
Yes
Mount Type:
Wall Mountable
Backlight Technology:
LED
Video
Maximum Resolution:
1920 x 1080
Standard Refresh Rate:
60 Hz
Color Supported:
16.7 Million Colors
Contrast Ratio:
1,000:1
Brightness:
250 Nit
Audio
Speakers:
Yes
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
Optical
Multi-touch Screen:
Yes
Interfaces/Ports
DVI:
Yes
HDMI:
Yes
USB:
Yes
USB Standard:
USB 2.0
VGA:
Yes
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
35 W
Standby Power Consumption:
400 mW
Off-Mode Power Consumption:
400 mW
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Product Color:
Black
Height:
15.5"
Width:
21.9"
Depth:
2.2"
Depth with Stand:
4.30"
Weight (Approximate):
19.84 lb
Miscellaneous
Package Contents:
  • PXL2430MW Touchscreen LCD Monitor
  • Power Cord
  • VGA Cable
  • DVI Cable
  • USB Cable
  • Audio-In Cable
  • User's Guide
Certifications & Standards:
  • cTUVus
  • FCC-B
  • CE
Platform Supported:
PC
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • WEEE
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0012300422185, 0810689063995, 0993242624106, 4923773150870
UPC: 012300422185, 027616895530, 810689063995, 993242624106
EAN: 0012300422185, 0810689063995, 0993242624106, 4923773150870
UNSPSC: 43211903
Questions? Get help from
a POS Expert!

What is your POS application?

The Planar PXL2430MW Touchscreen is also known as PXL2430MW
