Video Wall Compatible:
Yes
Bezel Width:
34.6 mil
Planar 998-2451-00 Digital Signage Display
Part Number:
998-2451-00
Model:
Parts
Planar Parts Accessory Model Overview
Products and parts from Planar.
Planar 998-2451-00 Digital Signage Display Overview
The Clarity® Matrix® G3 LX55M is a 55" LCD video wall display with a tiled bezel width of 0.88 mm that provides a nearly seamless digital canvas, outstanding tiled visual performance, extended operation and requires minimal installation space. The reduced weight of Clarity Matrix G3 LX55M facilitates increased durability and easier installation. User- selectable local dimming delivers the highest contrast ratio and black-level uniformity, for brighter whites and darker, more consistent, blacks. Designed for 24x7 operation, the Clarity Matrix G3 LX55M features 500 nits brightness, LED backlight technology and Full HD resolution making it the ideal video wall for high- impact, mission-critical applications
Technical Information
Display & Graphics
Number of Screens:
1
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Backlight Technology:
LED
Video
Scan Format:
1080p
Dynamic Contrast Ratio:
10,000:1
Brightness:
500 Nit
Network & Communication
Ethernet:
Yes
Interfaces/Ports
HDMI:
Yes
DisplayPort:
Yes
Serial:
Yes
Number of HDMI Inputs:
4
Number of DisplayPorts:
3
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Physical Characteristics
Mount Type:
Wall Mountable
Height:
26.8"
Width:
47.6"
Depth:
3.5"
Weight (Approximate):
47 lb
Miscellaneous
Package Contents:
- Clarity Matrix G3 LX55M-L-F Digital Signage Display
- 1 x LCD module
Item Numbers
UNSPSC:
43211902
