Planar 998-2158-00 Digital Signage Display

Part Number: 998-2158-00
Model: Parts
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size
75"
Display Screen Type
LCD
Display Screen Technology
In-plane Switching (IPS) Technology
Backlight Technology
Direct LED

Product Description:

  HB75, 75IN, 20PT PROJECTED CAPACITIVE TOUCH, UHD, LED BACKLIGHT,18X7, METAL BEZEL, LANDSCAPE ONLY, WIDE ARRAY OF INPUTS, EMBEDDED ANDROID 8.0, 350 NITS, SPEAKERS, RS232, LAN, WIFI, BLUETOOTH. INTEGRATED WHITEBOARD SOFTWARE AND OTHER
Explore all Planar Parts Accessories
Add to Quote
Planar 998-2158-00 Digital Signage Display
Planar 998-2158-00 Digital Signage Display

Planar Parts Accessory Model Overview

Products and parts from Planar.
Planar 998-2158-00 Digital Signage Display Overview

The Planar HB75 is a 75" huddle board display with 4K resolution and pinpoint-accurate, 20-point Projected Capacitive touch designed for in-room and remote collaboration. It features an embedded Android® operating system with a built-in digital whiteboard and pre-loaded collaboration applications. The display also has wireless connectivity and an OPS slot to support external devices such as a Window 10 PC. The display's passive and active stylus pens help ensure efficiency.

The Planar HB75 huddle board is compliant with United States Trade Agreements Act (TAA) regulations.

Display & Graphics
Screen Size:
75"
Display Screen Type:
LCD
Display Screen Technology:
In-plane Switching (IPS) Technology
Backlight Technology:
Direct LED
Screen Mode:
4K UHD
Screen Resolution:
3840 x 2160
Scan Format:
2160p
Aspect Ratio:
16:9
Response Time:
8 ms
Color Depth:
10-bit
Contrast Ratio:
1,000:1
Display Orientation:
Landscape
Brightness:
350 Nit
HDCP Supported:
Yes
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Touchscreen Information
Touchscreen:
Yes
Multi-touch Screen:
Yes
Number of Touch Points:
20
Touchscreen Technology:
Capacitive
Processor & Chipset
Processor Manufacturer:
ARM
Processor Type:
Cortex A73 + A53
Processor Speed:
1.50 GHz
Memory
Standard Memory:
3 GB
Memory Card Supported:
microSD
Storage
Flash Memory Capacity:
32 GB
Audio
Speakers:
Yes
Number of Speakers:
2.0
RMS Output Power:
30 W
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Wireless LAN:
Yes
Bluetooth:
Yes
Interfaces/Ports
HDMI:
Yes
Number of HDMI Inputs:
3
Number of HDMI Outputs:
1
Total Number of USB Ports:
2
Number of USB 2.0 Ports:
1
USB:
Yes
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Number of VGA Ports:
1
VGA:
Yes
DisplayPort:
Yes
Serial:
Yes
S/PDIF Out:
Yes
Software
Operating System Platform:
Android
Operating System:
Android
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Power Consumption:
295 W
Physical Characteristics
Product Material:
Metal
VESA Mount Compatible:
Yes
VESA Mount Standard:
600 x 400
Height:
40"
Width:
67.4"
Depth:
3.6"
Weight (Approximate):
106 lb
Miscellaneous
Package Contents:
  • 4K Touch Screen Collaboration Display
  • US power cord
  • HDMI cable
  • USB A to B cable
  • Remote control
  • 2 x WiFi antenna
  • 1 x Bluetooth antenna
  • 2 x Active stylus
  • 2 x Passive stylus
  • Cable clips
  • QuickStart Guide
Country of Origin:
Korea
TAA Compliant:
Yes
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0810689008057
UPC: 810689008057
EAN: 0810689008057
UNSPSC: 45111902
