Planar 997-8088-00 Digital Signage Display

Part Number: 997-8088-00
Model: UltraRes Series
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Features
4K UHDProgressive ScanPicture in PictureLandscape/Portrait ViewableScheduleOpen Pluggable Specification (OPS)
Screen Size
84"
Display Screen Type
LCD
Display Resolution
3840 x 2160

Product Description:

  Planar UltraRes UR8451-MX 4K LCD Display - 84" LCD - 3840 x 2160 - LED - 500 Nit - 2160p - HDMI - USB - SerialEthernet
Explore all Planar UltraRes Series Digital Signage Displays
Add to Quote
Planar 997-8088-00 Digital Signage Display
Planar 997-8088-00 Digital Signage Display
Planar 997-8088-00 Digital Signage Display
Planar 997-8088-00 Digital Signage Display Planar 997-8088-00 Digital Signage Display Planar 997-8088-00 Digital Signage Display
Full specifications (PDF)

Planar UltraRes Series Digital Signage Display Model Overview

The Planar UltraRes Series is a line of 75", 84" and 98" Ultra HD resolution (3840 x 2160) professional LCD displays with best-in-class image and color quality for native 4K and upscaled content. Planar UltraRes Series displays offer superior performance with exceptional 4K clarity and advanced processing ideal for applications ranging from collaborative meeting spaces to high impact digital signage.
Planar 997-8088-00 Digital Signage Display Overview
The Planar® UltraRes™ UR8451-MX is an 84" Ultra HD (3840 x 2160) professional LCD display with bestin-class image and color quality for native 4K and upscaled content. This 500 nit 84" display supports multi-source viewing, 4K @ 60Hz, HDCP 2.2 compliance, and portrait orientation. Planar UltraRes Series displays offer superior performance with exceptional 4K clarity and advanced processing ideal for applications ranging from collaborative meeting spaces to high impact digital signage.
Full specifications (PDF)
Technical Information
Features:
  • 4K UHD
  • Progressive Scan
  • Picture in Picture
  • Landscape/Portrait Viewable
  • Schedule
  • Open Pluggable Specification (OPS)
Display & Graphics
Screen Size:
84"
Display Screen Type:
LCD
Display Resolution:
3840 x 2160
Response Time:
5 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
LED
HDCP Supported:
Yes
Audio
Number of Speakers:
2
Speakers:
Yes
RMS Output Power:
20 W
Video
Scan Format:
2160p
Standard Refresh Rate:
60 Hz
Frame Refresh Rate:
120 Hz
Native Contrast Ratio:
1,400:1
Brightness:
500 Nit
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Interfaces/Ports
USB:
Yes
USB Standard:
  • USB 2.0
  • USB 3.0
HDMI:
Yes
DisplayPort:
Yes
Network (RJ-45):
Yes
Audio Line Out:
Yes
Serial:
Yes
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Power Consumption:
360 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
600 x 400
Height:
43.7"
Width:
75.5"
Depth:
3.6"
Weight (Approximate):
200 lb
Miscellaneous
Certifications & Standards:
  • FCC Class A
  • CE
  • TAA
  • cTUVus
    • Environmentally Friendly:
    Yes
    Warranty
    Limited Warranty:
    3 Year
    Item Numbers
    GTIN: 0810689002581
    UPC: 810689002581
    EAN: 0810689002581
    UNSPSC: 43211902
