Planar Clarity Matrix LX Digital Signage Display Model Overview
The Planar Clarity Matrix™ LCD Video Wall System with G2 Architecture delivers superior visual performance and mission-critical reliability for a diverse range of applications. Designed for 24/7 operation, its unique architecture minimizes installation depth while ensuring stunning visual quality with the industry's thinnest bezels at just 3.7mm. With features like the Planar® EasyAxis™ Mounting System and off-board electronics, it offers an effortless installation and maintenance experience, making it ideal for environments requiring exceptional display accuracy and durability. Key features:
Thin Bezels: Tiled bezel width as small as 3.7mm for seamless visuals.
Mission-Critical Design: Redundant power supplies ensure uninterrupted operation.
Flexible Mounting: Planar EasyAxis™ Mounting System for quick and precise alignment.
High Brightness Levels: Options available up to 800 nits.
MultiTouch Capabilities: Optional touch kit with up to 32 simultaneous touch points.
Specifications:
Diagonal Sizes: 46" and 55"
Brightness: 450 nits (LX models), 500 nits (MX models), up to 800 nits for certain models
Contrast Ratio: 3500:1
Operating Temperature: 5-40°C
Operating Humidity: 20-90% RH non-condensing
Resolution: 1920 x 1080 (Full HD)
Mounting Depth: 3.6" (93mm)
Power Consumption: Typical - 143-205 watts
Planar 997-7786-01 Digital Signage Display Overview
The Clarity® Matrix® MultiTouch Video Wall is anultra-slim profile touch screen video wall ideal forpublic spaces or collaboration environments. Utilizinga touch kit, Clarity® Matrix® LX55HDU-L-ERO can betransformed into a Clarity Matrix MultiTouch VideoWall featuring up to 32 touch points and allowsmultiple users to simultaneously interact with thevideo wall without affecting other users. Clarity MatrixMultiTouch with Planar® ERO™ (ExtendedRuggedness and Optics™) technology provides acontinuous touch surface while increasing durabilityand optical performance. Clarity Matrix LX55HDU-L-ERO features a tiled bezel width of 3.7mm and 500nits brightness.
An auto color balance tool used to measure the Clarity Matrix with G2 Architecture LCD modules, calculate, and automatically adjust for optimal color and brightness.
The Planar 997-7786-01 Digital Signage Display is also known as
997-7786-01
IMPORTANT UPDATE: Due to memory chip industry demands, manufacturers are signaling price increases and supply constraints. Contact us now to secure inventory and pricing.IMPORTANT UPDATE: Due to memory chip industry demands, manufacturers are signaling price increases and supply constraints. Contact us now to secure inventory and pricing.
Full specifications (PDF)
