Planar 997-7656-01 Digital Signage Display

The Planar 997-7656-01 Digital Signage Display has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Planar PS Series - Planar PS5561T Interactive Large Format Display - 55" LCD - Touchscreen - 1920 x 1080 - LED - 500 Nit - HDMI - USB - DVI - SerialEthernet

Digital Signage Display - Ideal for rack, passageway, booth or display counter
55" Signage Display - Designed for unwavering quality and dazzling picture clarity
Experience luminescent visual images with LCD display
Features full 1920 x 1080 HD resolution enabling sharp and clear images
LED backlight enhances display performance that delivers an outstanding color range and contrast ratios
Engages your customers and makes their viewing experience breathtaking with its 1080p content

Need a different version? See all Planar PS Series Digital Signage Displays

Discontinued Need Assistance?

Add to Quote

Planar 997-7656-01 Digital Signage Display

Overview

Full specifications (PDF)

Planar PS Series Digital Signage Display Model Overview

The Planar PS Series is a line of professional large format LCD displays that offer a full set of commercial-grade features with superior visual performance that is well-suited for demanding digital signage and corporate environments. Ranging in size from 46" - 82", the Planar PS Series features models available with media playback, interactive touch and narrow bezels. Engineered from the ground up for extended commercial use, each Planar PS Series model is recommended for up to 24x7 operation and comes standard with a durable metal bezel. At double the brightness of standard televisions, the Planar PS Series displays vibrant images and messaging that will captivate the attention of any audience.

Planar 997-7656-01 Digital Signage Display Overview

The Planar® PS5561T is a 55" commercial-grade,multi-touch LCD display offering up to 6 touch points and is compatible with Windows, MacOS X and Linux. The Planar PS5561T is the ideal combination of value, performance and 24x7 reliability for interactive applications

Detailed Specs

Full specifications (PDF)

Technical Information

Features:

Progressive Scan
Landscape/Portrait Viewable
On/Off Scheduling
Pivot Display

Display & Graphics

Screen Size:

55"

Display Screen Type:

LCD

Touchscreen:

Yes

Touchscreen Technology:

Infrared (IrDA)

Multi-touch Screen:

Yes

Display Resolution:

1920 x 1080

Response Time:

6.50 ms

Aspect Ratio:

16:9

Horizontal Viewing Angle:

178°

Vertical Viewing Angle:

178°

Backlight Technology:

LED

Audio

Number of Speakers:

Speakers:

Yes

RMS Output Power:

20 W

Video

Scan Format:

1080p

Standard Refresh Rate:

60 Hz

Native Contrast Ratio:

4,000:1

Brightness:

500 Nit

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Ethernet

Interfaces/Ports

USB:

Yes

DVI:

Yes

VGA:

Yes

HDMI:

Yes

DisplayPort:

Yes

Network (RJ-45):

Yes

Audio Line In:

Yes

Audio Line Out:

Yes

Serial:

Yes

Power Description

Input Voltage:

120 V AC
230 V AC

Power Consumption:

165 W

Physical Characteristics

Color:

Black

VESA Mount Compatible:

Yes

VESA Mount Standard:

400 x 200

Height:

28.7"

Width:

49.5"

Depth:

2.8"

Weight (Approximate):

91 lb

Miscellaneous

Package Contents:

PS5561T Interactive Large Format Display
Power cord
VGA cable
IR extender cable
Remote control
USB cable

Certifications & Standards:

FCC Class A
UL
CE
TAA

Warranty

Limited Warranty:

3 Year

Item Numbers

UNSPSC: 43211902
