Planar 997-7564-01 Monitor

Planar - FRU CLARITY MATRIX , MX55HDU L LCD
  • Available in 55" with 1920 x 1080 resolution
  • Tiled bezel widths ranging from 1.7mm-3.7mm
  • 800 nits brightness
  • Off-board electronics design reduces depth, weight, heat and points of potential failure
  • Planar EasyAxis Mounting System optimizes mounting, alignment and service
Read More

Need a different version? See all Planar Parts Accessories

$7,833.00
Chat Now for Qty Discount
Add to Quote
Add to My Shopping List Add to Compare
Planar 997-7564-01 Monitor
Planar 997-7564-01 Monitor
Planar 997-7564-01 Monitor
Planar Parts Accessory Model Overview
Products and parts from Planar.
Planar 997-7564-01 Monitor Overview
The Clarity® Matrix® MX55HDU-L is an ultra-narrow bezel 55" LCD video wall display that provides outstanding tiled visual performance, supports extended operation, and requires minimal installation space. Designed for 24x7 operation, Clarity Matrix MX55HDU-L features 800 nits brightness, LED backlight technology, and Full HD resolution making it the ideal video wall for high-impact, mission-critical applications. Clarity Matrix MX55HDU-L features a tiled bezel width of just 3.7mm.
Technical Information
Video Wall Compatible:
Yes
Bezel Width:
0.15"
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Backlight Technology:
LED
Video
Scan Format:
1080p
Brightness:
800 Nit
Network & Communication
Ethernet:
Yes
Interfaces/Ports
HDMI:
Yes
Serial:
Yes
Number of HDMI Inputs:
4
Number of DisplayPorts:
1
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Physical Characteristics
Height:
26.9"
Width:
47.8"
Depth:
3.6"
Weight (Approximate):
59 lb
Miscellaneous
Environmentally Friendly:
Yes
Country of Origin:
United States
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC: 43211902
