Video Wall Compatible:
Yes
Bezel Width:
0.15"
Planar 997-7564-01 Monitor
Part Number:
997-7564-01
Model:
Parts
Planar Parts Accessory Model Overview
Products and parts from Planar.
Planar 997-7564-01 Monitor Overview
The Clarity® Matrix® MX55HDU-L is an ultra-narrow bezel 55" LCD video wall display that provides outstanding tiled visual performance, supports extended operation, and requires minimal installation space. Designed for 24x7 operation, Clarity Matrix MX55HDU-L features 800 nits brightness, LED backlight technology, and Full HD resolution making it the ideal video wall for high-impact, mission-critical applications. Clarity Matrix MX55HDU-L features a tiled bezel width of just 3.7mm.
Technical Information
Display & Graphics
Viewable Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Backlight Technology:
LED
Video
Scan Format:
1080p
Brightness:
800 Nit
Network & Communication
Ethernet:
Yes
Interfaces/Ports
HDMI:
Yes
Serial:
Yes
Number of HDMI Inputs:
4
Number of DisplayPorts:
1
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Physical Characteristics
Height:
26.9"
Width:
47.8"
Depth:
3.6"
Weight (Approximate):
59 lb
Miscellaneous
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Country of Origin:
United States
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC:
43211902
The Planar 997-7564-01 Monitor is also known as
997-7564-01
