Full specifications (PDF)
Features:
- Safety Lock
- Landscape/Portrait Viewable
- Ultra Slim
Planar 997-7435-00 Digital Signage Display
Part Number:
997-7435-00
Model:
Simplicity Series
Planar Simplicity Series Digital Signage Display Model Overview
The Planar Simplicity Series line of LCD displays for digital signage incorporates media playing, a sleek design and commercial functionality into an affordable digital signage solution. Ranging in size from 32" - 55", Planar Simplicity Series displays eliminate the need for additional hardware, reducing installation cost and complexity.
Planar 997-7435-00 Digital Signage Display Overview
The Planar® SL5550 is a 55" LCD display for digital signage that incorporates media playing, a sleek design and commercial functionality into an affordable 55" digital signage solution. Its elegant design with logo-free, symmetrical bezel and ultra-slim profile provide the ideal display solution for digital signage applications in retail stores, restaurants, medical offices, corporate meeting areas and hospitality.
Technical Information
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Response Time:
8 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
Edge LED
Audio
Number of Speakers:
2
Speakers:
Yes
RMS Output Power:
14 W
Video
Scan Format:
1080p
Standard Refresh Rate:
60 Hz
Native Contrast Ratio:
1,400:1
Brightness:
350 Nit
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Interfaces/Ports
USB:
Yes
DVI:
Yes
VGA:
Yes
HDMI:
Yes
Component Video:
Yes
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Serial:
Yes
Power Description
Input Voltage:
- 110 V AC
- 220 V AC
Power Consumption:
128 W
Physical Characteristics
Color:
Black
VESA Mount Compatible:
Yes
VESA Mount Standard:
400 x 400
Height:
28.9"
Width:
49.8"
Depth:
1.7"
Weight (Approximate):
21.20 lb
Miscellaneous
Package Contents:
- SL5550 Large Format Display
- VGA cable
- Power cord
- RS-232 cable
- Remote control
- Cable clamps
Certifications & Standards:
- CE
- FCC Class B
- UL
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN:
0810689000303
UPC:
810689000303
EAN:
0810689000303
UNSPSC:
43211902
Get help from a Barcoding Expert!
The Planar 997-7435-00 Digital Signage Display is also known as
997-7435-00
