Planar 997-7251-01 Touchscreen

Part Number: 997-7251-01
Model: Parts
to get Free Ground Shipping on your order.
Add to My Shopping List Add to Compare
$474.15

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
22"
Viewable Screen Size
21.5"
Screen Mode
Full HD
Response Time
18 ms Typical

Product Description:

  Touchscreens, Planar Helium PCT2265, 21.5" Multi-Touch Monitor, Full HD 1920 x 1080 at 76 Hz, HDMI/DVI-D/VGA, 18 ms Response Time (GtG), Stereo Speakers/4-Port USB Hub
Explore all Planar Parts Accessories
Add to Quote
Planar 997-7251-01 Touchscreen
Planar 997-7251-01 Touchscreen
Planar 997-7251-01 Touchscreen
Planar 997-7251-01 Touchscreen
Planar 997-7251-01 Touchscreen
Planar 997-7251-01 Touchscreen Planar 997-7251-01 Touchscreen Planar 997-7251-01 Touchscreen Planar 997-7251-01 Touchscreen Planar 997-7251-01 Touchscreen

Planar Parts Accessory Model Overview

Products and parts from Planar.
Planar 997-7251-01 Touchscreen Overview
The Planar® Helium™ PCT2265 is a 22" , Full HD, multi-point touch screen LCD monitor that provides the ultimate desktop touch experience. It uses accurate projected capacitive technology that registers up to 10 simultaneous touch points, and the easy-to-use dual-hinge Helium™ Desk Stand facilitates tilting from 0 to 90 degrees. Inputs include HDMI and DVI-D. A USB 3.0 hub is built into the monitor to connect additional peripherals.
Technical Information
Screen Size Class:
22"
Viewable Screen Size:
21.5"
Screen Mode:
Full HD
Response Time:
18 ms Typical
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
Edge LED
HDCP Supported:
Yes
Features:
Cable Lock Slot
Video
Maximum Resolution:
1920 x 1080
Standard Refresh Rate:
75 Hz
Color Supported:
16.7 Million Colors
Native Contrast Ratio:
3,000:1
Brightness:
250 Nit
Audio
Speakers:
Yes
Touchscreen Information
Touchscreen Type:
Projected Capacitive
Multi-touch Screen:
Yes
Number of Simultaneous Touchpoints:
10
Interfaces/Ports
DVI:
Yes
HDMI:
Yes
USB:
Yes
VGA:
Yes
Built-in Devices
Built-in Devices:
USB Hub
Power Description
Operating Power Consumption:
28 W
Physical Characteristics
VESA Mount Compatible:
Yes
Product Color:
Black
Height:
12.5"
Width:
20.6"
Depth:
2.5"
Height with Stand:
15.16"
Width with Stand:
20.57"
Depth with Stand:
9.39"
Weight (Approximate):
9.50 lb
Weight with Stand (Approximate):
14.60 lb
Miscellaneous
Package Contents:
  • PCT2265 22" Wide Multi-Touch Monitor
  • Power Cord
  • VGA Cable
  • DVI-D cable
  • HDMI Cable
  • USB Cable (A to B)
  • Audio-in Cable
  • User's Guide
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0810069810270
UPC: 810069810270
EAN: 0810069810270
UNSPSC: 43211903
