Full specifications (PDF)
Features:
- Video Wall
- Progressive Scan
Planar 997-7218-00 Digital Signage Display
Part Number:
997-7218-00
Model:
Clarity Matrix LX
Planar Clarity Matrix LX Digital Signage Display Model Overview
The Planar Clarity Matrix™ LCD Video Wall System with G2 Architecture delivers superior visual performance and mission-critical reliability for a diverse range of applications. Designed for 24/7 operation, its unique architecture minimizes installation depth while ensuring stunning visual quality with the industry's thinnest bezels at just 3.7mm. With features like the Planar® EasyAxis™ Mounting System and off-board electronics, it offers an effortless installation and maintenance experience, making it ideal for environments requiring exceptional display accuracy and durability.
Key features:
Specifications:
Key features:
- Thin Bezels: Tiled bezel width as small as 3.7mm for seamless visuals.
- Mission-Critical Design: Redundant power supplies ensure uninterrupted operation.
- Flexible Mounting: Planar EasyAxis™ Mounting System for quick and precise alignment.
- High Brightness Levels: Options available up to 800 nits.
- MultiTouch Capabilities: Optional touch kit with up to 32 simultaneous touch points.
Specifications:
- Diagonal Sizes: 46" and 55"
- Brightness: 450 nits (LX models), 500 nits (MX models), up to 800 nits for certain models
- Contrast Ratio: 3500:1
- Operating Temperature: 5-40°C
- Operating Humidity: 20-90% RH non-condensing
- Resolution: 1920 x 1080 (Full HD)
- Mounting Depth: 3.6" (93mm)
- Power Consumption: Typical - 143-205 watts
Technical Information
Display & Graphics
Screen Size:
46"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Response Time:
8 ms
Aspect Ratio:
16:9
Video
Scan Format:
1080p
Dynamic Contrast Ratio:
3,500:1
Brightness:
500 Nit
Miscellaneous
Certifications & Standards:
TAA
Item Numbers
UNSPSC:
43211902
Recommended Accessories
Category
- Digital Signage Display (1)
- Digital Signage Display Accessories (27)
Recommended Accessories for Model: Planar 997-7218-00 Digital Signage Display
Top Digital Signage Display Purchased With Planar 997-7218-00
-
Planar 997-7803-00 Digital Signage DisplayPlanar Clarity Matrix LX46HDU LCD Video Wall System - 46" LCD - 1920 x 1080 - Direct LED - 500 Nit - HDMI - Serial$5,643.00
Top Digital Signage Display Accessories Purchased With Planar 997-7218-00
-
Planar 175-0999-00 Accessory25-foot (7.6-meter) Primary Power Cable - to provide a 48V power connection from the Power Supply Module to the display.$112.42 -
Planar 175-0899-00 Accessory100-foot (33-meter) Primary Power Cable - to provide a 48V power connection from the Power Supply Module to the display.$390.68 -
Planar 175-0993-00 Accessory8-foot (2.5-meter) Interconnect Power Cable - to provide a 48V power connection between 1 display and the next display in a daisy-chained group.$78.78
