Full specifications (PDF)
Features:
- Video Wall
- Progressive Scan
- Ambient Light Sensor
Planar 997-7216-00 Digital Signage Display
Part Number:
997-7216-00
Model:
Clarity Matrix MX
Planar Clarity Matrix MX Digital Signage Display Model Overview
The Clarity Matrix LCD Video Wall System with G2 Architecture is designed to deliver unparalleled visual performance and operational reliability for mission-critical applications. This advanced video wall solution features the industry’s thinnest bezel, ensuring a sleek design that minimizes installation space while maximizing flexibility. With an innovative EasyAxis Mounting System for effortless alignment and a robust rack-mounted electronics architecture, the Clarity Matrix simplifies set-up and maintenance, significantly reducing the total cost of ownership and enhancing overall display reliability.
Key features:
Specifications:
Key features:
- Thinnest bezel width: As small as 3.7 mm
- Integrated EasyAxis Mounting System: Ensures perfect alignment and easy service access
- Flexible windowing capability: Allows simultaneous content display
- High brightness options: Available brightness levels of 450 nits and 800 nits
- Ultra High Definition: Supports 4K resolution across multiple displays
- Redundant power supplies: Enhances reliability with uninterrupted operation
Specifications:
- Diagonal Sizes: 46" and 55"
- Brightness: Optimal levels of 450 nits to 800 nits
- Contrast Ratio: 3500:1 to 4500:1
- Resolution: Up to 1920 x 1080
- Operating Temperature: 5-40°C
- Power Consumption: Typical 143-205 watts
- Installation Depth: As thin as 3.6" (93mm)
- Weight: 42 lbs (19 kg) to 74 lbs (33.6 kg) depending on model
Planar 997-7216-00 Digital Signage Display Overview
The Clarity™ Matrix MX55HDS-L with G2 Architecture is an ultra-narrow bezel 55" LCD video wall display that provides outstanding tiled visual performance, supports extended operation and requires minimal installation space. Designed for 24x7 operation, the Clarity Matrix MX55HDS-L features 800 nits brightness, LED backlight technology and Full HD resolution making it the ideal video wall for high- impact, mission-critical applications. Clarity Matrix MX55HDS-L features a tiled bezel width as small as 5.5 mm, creating a near seamless digital canvas.
Technical Information
Display & Graphics
Screen Size:
55"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Response Time:
8 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
LED
Video
Scan Format:
1080p
Dynamic Contrast Ratio:
3,500:1
Brightness:
800 Nit
Interfaces/Ports
HDMI:
Yes
DisplayPort:
Yes
Serial:
Yes
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Power Consumption:
228 W
Physical Characteristics
VESA Mount Compatible:
Yes
Miscellaneous
Certifications & Standards:
- TAA
- EN60950
- FCC Class A
- CISPR22/85
- CE
Environmentally Friendly:
Yes
Environmental Certification:
EU RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
UNSPSC:
43211902
Recommended Accessories
Category
- Digital Signage Display Accessories (24)
- General Software (1)
Recommended Accessories for Model: Planar 997-7216-00 Digital Signage Display
Top Digital Signage Display Accessories Purchased With Planar 997-7216-00
-
Planar 175-0999-00 Accessory25-foot (7.6-meter) Primary Power Cable - to provide a 48V power connection from the Power Supply Module to the display.$112.42 -
Planar 175-0899-00 Accessory100-foot (33-meter) Primary Power Cable - to provide a 48V power connection from the Power Supply Module to the display.$390.68 -
Planar 175-0993-00 Accessory8-foot (2.5-meter) Interconnect Power Cable - to provide a 48V power connection between 1 display and the next display in a daisy-chained group.$62.45
Top General Software Purchased With Planar 997-7216-00
-
Planar 997-7432-00 SoftwareAn auto color balance tool used to measure the Clarity Matrix with G2 Architecture LCD modules, calculate, and automatically adjust for optimal color and brightness.Please Call for Pricing or to Purchase
