Full specifications (PDF)
Features:
- Media Player
- Video Wall
- Landscape/Portrait Viewable
- On/Off Scheduling
- Ultra Slim
Planar PS Series Digital Signage Display Model Overview
The Planar PS Series is a line of professional large format LCD displays that offer a full set of commercial-grade features with superior visual performance that is well-suited for demanding digital signage and corporate environments. Ranging in size from 46" - 82", the Planar PS Series features models available with media playback, interactive touch and narrow bezels. Engineered from the ground up for extended commercial use, each Planar PS Series model is recommended for up to 24x7 operation and comes standard with a durable metal bezel. At double the brightness of standard televisions, the Planar PS Series displays vibrant images and messaging that will captivate the attention of any audience.
Planar 997-7094-00 Digital Signage Display Overview
The Planar® PS6552 is a slim 65" LCD display designed for demanding digital signage and commercial applications. The Planar PS6552 is the ideal combination of value, performance and 24x7 reliability with the design and energy saving benefits of LED technology.
Technical Information
Display & Graphics
Screen Size:
65"
Display Screen Type:
LCD
Display Resolution:
1920 x 1080
Response Time:
8 ms
Aspect Ratio:
16:9
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Backlight Technology:
Edge LED
Audio
Number of Speakers:
2
Speakers:
Yes
RMS Output Power:
20 W
Video
Scan Format:
1080p
Standard Refresh Rate:
60 Hz
Native Contrast Ratio:
4,000:1
Brightness:
450 Nit
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Interfaces/Ports
USB:
Yes
DVI:
Yes
VGA:
Yes
HDMI:
Yes
Composite Video:
Yes
DisplayPort:
Yes
Network (RJ-45):
Yes
Audio Line In:
Yes
Audio Line Out:
Yes
Serial:
Yes
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Power Consumption:
300 W
Physical Characteristics
Product Color:
Black
VESA Mount Compatible:
Yes
VESA Mount Standard:
400 x 400
Height:
34.8"
Width:
59.9"
Depth:
3.2"
Weight (Approximate):
110 lb
Miscellaneous
Package Contents:
- PS6552 Digital Signage Display
- Power cord
- VGA cable
- IR extender cable
- Remote control
Certifications & Standards:
- FCC Class B
- cTUVus
- CE
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN:
0810689000099
UPC:
810689000099
EAN:
0810689000099
UNSPSC:
43211902
Get help from a Barcoding Expert!
The Planar 997-7094-00 Digital Signage Display is also known as
997-7094-00
