Planar 997-6314-00 Touchscreen

Part Number: 997-6314-00
Model: PT1785P
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Screen Size Class
17"
Viewable Screen Size
17"
Screen Mode
SXGA
Response Time
5 ms

Product Description:

  Planar PT1785P 17" LCD Touchscreen Monitor - 5:4 - 5 ms - 17" Class - Projected CapacitiveMulti-touch Screen - 1280 x 1024 - SXGA - Adjustable Display Angle - 16.7 Million Colors - 1,000:1 - 250 Nit - Speakers - USB - VGA - Black - RoHS - 3 Year
Explore all Planar PT1785P Touchscreens
Add to Quote
Planar 997-6314-00 Touchscreen
Planar 997-6314-00 Touchscreen
Planar 997-6314-00 Touchscreen
Planar 997-6314-00 Touchscreen
Planar 997-6314-00 Touchscreen Planar 997-6314-00 Touchscreen Planar 997-6314-00 Touchscreen Planar 997-6314-00 Touchscreen

Planar PT1785P Touchscreen Model Overview

The PT1785P 17" multi-touch zero bezel monitor is perfect for use in retail, hospitality, healthcare and kiosk applications. Easily integrated with a variety of thin client or PC systems, the monitor features a projected capacitive touch screen and USB touch screen interface. No drivers are needed for basic touchscreen operation, but for advanced features, drivers are quickly and easily loaded.
Planar 997-6314-00 Touchscreen Overview

The PT1785P 17" multi-touch zero bezel monitor is perfect for use in retail, hospitality, healthcare and kiosk applications. Easily integrated with a variety of thin client or PC systems, the monitor features a projected capacitive touch screen and USB touch screen interface. No drivers are needed for basic touchscreen operation, but for advanced features, drivers are quickly and easily loaded.

Technical Information
Screen Size Class:
17"
Viewable Screen Size:
17"
Screen Mode:
SXGA
Response Time:
5 ms
Aspect Ratio:
5:4
Horizontal Viewing Angle:
160°
Vertical Viewing Angle:
160°
Adjustable Display Angle:
Yes
Mount Type:
  • Arm-mountable
  • Wall Mountable
Video
Maximum Resolution:
1280 x 1024
Standard Refresh Rate:
60 Hz
Color Supported:
16.7 Million Colors
Contrast Ratio:
1,000:1
Brightness:
250 Nit
Audio
Speakers:
Yes
Touchscreen Information
Touchscreen:
Yes
Touchscreen Type:
Projected Capacitive
Multi-touch Screen:
Yes
Interfaces/Ports
USB:
Yes
VGA:
Yes
Built-in Devices
Built-in Devices:
Speaker
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
28 W
Standby Power Consumption:
3 W
Off-Mode Power Consumption:
1 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Color:
Black
Height:
14.6"
Width:
15.7"
Depth:
8.9"
Weight (Approximate):
16.30 lb
Miscellaneous
Package Contents:
  • PT1785P Touchscreen LCD Monitor
  • Power Cord
  • VGA Cable
  • Landing Strip
  • Cable Cover
  • USB Cable (A to B)
  • Audio-in Cable
  • CD-ROM (Driver)
  • User's Guide
  • Quick Start Guide
  • Screw
Certifications & Standards:
  • UL/c-UL
  • CSA
  • FCC-Class B
  • TUV-T mark
  • CE
Platform Supported:
  • PC
  • Mac
Environmentally Friendly:
Yes
Environmental Certification:
RoHS
Warranty
Limited Warranty:
3 Year
Item Numbers
GTIN: 0810689063148
UPC: 810689063148
EAN: 0810689063148
UNSPSC: 43211903
