The QuickScan QBT2131 features both Bluetooth Wireless Technology and Datalogic's STAR2.0 Cordless System for flexible cordless operation. Both connectivity options provide a radio range of 25 meters (82 feet) in open air, allowing you to scan from a distance while maintaining productivity across your warehouse or retail environment. We offer this scanner with either connectivity option to match your existing infrastructure.

The Magellan 9300i features digital imagers in all planes that enable it to read both 1D and 2D barcodes seamlessly without requiring item orientation by the cashier. This multi-plane imaging capability ensures reliable decoding of a wide range of barcode formats commonly used in retail and checkout environments.

The Heron HD3100 decodes 1D/linear codes, postal codes, and stacked codes including GS1 DataBar variants. It features Datalogic's patented 'Green Spot' technology for reliable good-read feedback, making it ideal for high-volume retail environments where fast, accurate scanning is essential.

The Heron HD3430 is a 2D area imager that reads both 1D and 2D barcodes with advanced reading technology. It features a Wide VGA imager sensor (752 x 480 pixels) with a maximum resolution of 4 mils, allowing it to capture standard linear codes, 2D codes like Data Matrix, and postal codes. The scanner also includes image capture capabilities in multiple graphic formats including BMP, JPEG, and TIFF.

The Magellan 9400i reads both 1D and 2D barcodes seamlessly without requiring item orientation. It supports various 1D codes, stacked codes including GS1 DataBar composites, and 2D codes such as QR Code, Data Matrix, and Aztec Code. This full digital imaging capability makes it an effective replacement for traditional laser scanners in retail environments.

Yes, the QuickScan QBT2131 is specifically designed for reading long linear barcodes thanks to its extra-wide scan angle and extra-long scan line. The scanner features a 56° field of view and can read barcodes at various distances depending on print resolution—for example, 20-mil codes can be read from 4 to 70 centimeters (1.5 to 27.5 inches). This makes it ideal for inventory management, retail checkout, and utilities applications where long barcode scanning is common.

Yes, the Magellan 9400i is specifically designed with ergonomic comfort for both seated and standing cashiers. It features a more traditional bonnet height with large horizontal and vertical windows that allow optimum positioning for POS touchscreens, payment terminals, and printers while maintaining ease of use regardless of the cashier's position.

The Heron HD3430 offers variable reading ranges depending on barcode type and print quality. For Code 39 (5 mils), the typical depth of field is 3.5 to 20.0 cm (1.3 to 7.8 inches); for EAN-13 (13 mils), it's 3.0 to 40.0 cm (1.2 to 15.7 inches); and for Data Matrix (15 mils), it's 2.0 to 25.0 cm (0.8 to 9.8 inches). Reading ranges are dependent on printing resolution, contrast, and ambient light conditions.

Yes, the Magellan 9300i is designed to maintain ergonomic comfort for both seated and standing cashiers. It features a more traditional bonnet height and large horizontal and vertical windows that allow optimum positioning for POS or self-checkout touchscreens, payment terminals, and printers.

We offer the Heron HD3100 with multi-interface support including RS-232, USB, and keyboard wedge connectivity. This flexibility allows seamless integration with existing POS systems and retail infrastructure without requiring major hardware modifications.

The QuickScan QBT2131 is equipped with a Lithium-Ion 1400 mAh battery that provides 30,000+ reads per charge. The scanner supports multiple charging options including USB, microUSB, and a charging base, with external power charging taking less than 3 hours at 12 VDC. Battery replacement is tool-free, making maintenance quick and convenient for your team.

The Magellan 9400i includes ScaleSentry™ technology for loss prevention and monitoring, helping retailers track and prevent shrinkage. Combined with its integrated scale platter that accommodates larger items for weighing, this scanner/scale combination provides comprehensive point-of-sale security and inventory control.

The Magellan 9300i supports RS-232 connectivity for both the scanner and scale, with options for single cable RS-232 integration. The device is also compliant with WMI (OPOS and JavaPOS) standards and supports host download capabilities including IBM Systems Director, Wavelink Avalanche, and other ERP management solutions.

The Heron HD3430 supports multiple interface options including USB, RS-232, Keyboard Wedge, and OEM (IBM) connectivity. This multi-interface capability makes it flexible for integration into various point-of-sale and warehouse management systems available from us.

The HD3100 is built to withstand the demands of busy retail settings with drop resistance from 1.5 meters (5.0 feet) onto concrete surfaces. It features IP40 sealing and operates reliably across temperatures from 0 to 50°C, making it suitable for both standard and demanding retail environments.

The Heron HD3430 is built to withstand harsh conditions with IP40 particulate and water sealing, 16 kV ESD protection (air discharge), and the ability to withstand repeated drops from 1.5 m (5.0 ft) onto concrete surfaces. It operates reliably in temperatures from 0 to 50°C (32 to 122°F) and handles humidity levels from 5 to 90% non-condensing, making it suitable for warehouse and logistics environments.

Yes, the Magellan 9300i includes the All-Weighs Scale Platter with integrated horizontal and vertical scale platter surfaces that increase the active weighing area for easy and accurate weighing of large items. It also features ScaleSentry Shrink Monitoring and Prevention System with configurable audio and visual indicators to identify items placed outside the weighing surface.

The QuickScan QBT2131 is built for demanding environments with drop resistance that withstands repeated drops from 1.5 meters (5.0 feet) onto concrete surfaces. It operates reliably across a temperature range of 0 to 50°C (32 to 122°F) and features IP42 particulate and water sealing protection. The scanner also includes 16 kV ESD protection and maintains 90% humidity tolerance, making it suitable for various warehouse and retail conditions.

The Magellan 9400i requires AC input of 100-240 VAC with nominal power consumption of 12 Watts. It operates in environmental conditions ranging from 10 to 40 °C with humidity levels between 5-95%, making it suitable for standard retail environments. The unit comes with a 1-Year Factory Warranty.

The Heron HD3100 delivers 270 reads per second with a maximum reading range of up to 60.0 cm (23.6 inches) and resolution down to 0.100 mm (4 mils). This high-speed performance ensures quick checkout transactions and efficient barcode capture across various label sizes and distances.

The Heron HD3430 includes multiple good-read feedback mechanisms: polyphonic beepers with adjustable tone and volume, Datalogic's proprietary 'Green Spot' visual feedback, product side and upper illumination, and a Good Read LED indicator. These multi-sensory confirmations ensure operators receive clear feedback during point-of-sale transactions.

Yes, the Magellan 9400i features Remote Management capabilities for easy integration with POS systems. This allows retailers to manage and monitor the scanner remotely, streamlining deployment and maintenance across multiple checkout locations.

The Magellan 9300i offers dual interval scale options. The dual interval scale provides Range 1 capacity of 0-6.0 kg (0-15.0 lb) with 0.002 kg (0.005 lb) minimum increment, and Range 2 capacity of 6.0-15.0 kg (15.0-30.0 lb) with 0.005 kg (0.010 lb) minimum increment. A single interval scale option is also available with 0-15.0 kg (0-30.0 lb) capacity.

Yes, the HD3100 offers customization options including a choice of black or white base colors, carbon-fiber or silver top cap designs, and the ability to add custom logos for minimum quantity purchases. This allows you to reinforce your brand identity at the point-of-sale while maintaining the scanner's elegant design.

The QuickScan QBT2131 auto-discriminates all standard 1D linear barcodes, including GS1 DataBar linear codes and postal codes. This versatility makes it compatible with most barcode systems used in retail, inventory, and logistics operations. Contact us today to confirm compatibility with your specific barcode formats.

The Heron HD3430 measures 15.2 x 15.3 x 6.8 cm (6.0 x 6.0 x 2.7 inches) and weighs 150.0 g (5.3 oz), featuring a streamlined scanner body with a carbon-fiber top cap design available in silver. The scanner is available in black and white colors, with custom logo options available for minimum quantity purchases. Contact us today to discuss your specific color and customization needs.

The Magellan 9400i offers optional features including a Customer Service Scanner (CSS) for easy mobile coupon scanning, enabling retailers to engage customers in mobile commerce and significantly reduce transaction times. The All-Weighs Scale Platter accommodates larger items for weighing, and the 9400i series supports optional Digimarc® Barcode digital watermark decoding.

The Magellan 9300i supports integration with multiple EAS systems. For Sensormatic, it uses Datalogic SmartSentry Firmware technology to interface with the Sensormatic AMB-9010/IPS and ScanMax Pro EAS Deactivation Controllers. For Checkpoint Systems, the integrated EAS hardware works with Counterpoint IX and Evolve D11 models. Both configurations include good read and EAS status indicators.

We offer the Heron HD3100 with a comprehensive 5-year factory warranty to protect your investment. Contact us today at 1-833-299-1662 or visit barcodesinc.com to learn more about our support options and to place your order.

Yes, the QuickScan QBT2131 includes Batch Mode capability, allowing it to store over 500 linear codes for later transmission. This feature is particularly useful in environments where continuous connectivity is not available, enabling you to scan and store data offline before syncing with your system. Combined with the scanner's cordless design, batch mode increases flexibility for mobile inventory operations.
