Panasonic CF-H1CEKTZ6M Tablet

Part Number: CF-H1CEKTZ6M

Model: Toughbook H1 Health

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Processor Manufacturer

Intel

Processor Type

Atom

Processor Model

Z540

Processor Speed

1.86 GHz

Product Description:

Panasonic Toughbook H1 CF-H1CEKTZ6M Rugged Tablet - 10.4" XGA - 2 GB RAM - Windows 7 - Intel SoC - Intel Atom Z540 Single-core (1 Core) 1.86 GHz - 1024 x 768 - 6 Hour Maximum Battery Run Time

Explore all Panasonic Toughbook H1 Health Tablets

Add to Quote

Overview

Full specifications (PDF)

Panasonic Toughbook H1 Health Tablet Model Overview

Based on Intel's reference design, Panasonic's new Toughbook H1 mobile clinical assistant (MCA), features a bright 10.4" dual-touch display that offers both tablet and touchscreen functionality. Weighing only 3.4 lbs, with hot swappable twin batteries, this mobile computing platform features an 80GB shock-mounted hard drive, the latest Intel mobile processor technology, embedded wireless capabilities, and is designed to meet the specific needs of healthcare professionals.

Panasonic CF-H1CEKTZ6M Tablet Overview

In your world, you have to know things they can't tell you. When the pressure is high, the hours are long, and contact with germs and viruses is inevitable, you need a reliable and secure mobile computer that can keep up with a rigorous day in the ER. The ultra-mobile-rugged Panasonic Toughbook H1 Health is built specifically for the healthcare industry. This fully-sealed mobile clinical assistant device is easily sanitized to prevent the transfer of disease throughout the facility. From the hospital to home care, the Toughbook H1 Health runs a full OS (Windows Vista or XP) seamlessly in a compact and lightweight design. Plus, with long-lasting hot-swappable twin batteries, the Toughbook H1 Health endures demanding shifts without slowing you down.

Detailed Specs

Full specifications (PDF)

Processor

Processor Manufacturer:

Intel

Processor Type:

Atom

Processor Model:

Z540

Processor Speed:

1.86 GHz

Processor Core:

Single-core (1 Core)

Cache:

512 KB

Bus Speed:

533 MHz

Chipset

Chipset Manufacturer:

Intel

Memory

Standard Memory:

2 GB

Maximum Memory Supported:

2 GB

Memory Technology:

DDR2 SDRAM

Storage

Hard Drive Capacity:

80 GB

Solid State Drive Capacity:

Optical Drive Type:

Display & Graphics

Screen Size:

10.4"

Display Screen Type:

Active Matrix TFT Color LCD

Aspect Ratio:

4:3

Screen Mode:

XGA

Screen Resolution:

1024 x 768

Touchscreen:

Yes

Digitizer:

Yes

Graphics Controller Manufacturer:

Intel

Graphics Controller Model:

Graphics Media Accelerator 500

Graphics Memory Capacity:

256 MB

Graphics Memory Technology:

DDR2 SDRAM

Graphics Memory Accessibility:

Shared

Network & Communication

WWAN Supported:

Yes

GPS:

Yes

Wireless LAN:

Yes

Wireless LAN Manufacturer:

Intel

Wireless LAN Model:

WiFi Link 5100

Wireless LAN Standard:

IEEE 802.11n

Bluetooth:

Yes

Bluetooth Standard:

Bluetooth 2.0

Input Devices

Pointing Device Type:

Stylus

Built-in Devices

Front Camera:

Yes

Finger Print Reader:

Yes

Operating System

Operating System Platform:

Windows

Operating System:

Windows 7

Downgradable Operating System:

Windows XP Tablet PC Edition

Software

Software Included:

Setup
Diagnostics
Adobe Reader
Panasonic Dashboard
PC Information Viewer
Cleaning Reminder Tool
Keyboard Button Manager
Panasonic Handwriting Tool
Hard Disk Data Erase Utility

Battery Information

Number of Batteries Supported:

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Capacity:

2900 mAh

Maximum Battery Run Time:

6 Hours

Physical Characteristics

Rugged:

Yes

Form Factor:

Slate

Height:

2.3"

Width:

10.6"

Depth:

10.4"

Miscellaneous

Package Contents:

TOUGHBOOK CF-H1CEKTZ6M Tablet PC
Lithium-Ion Batteries
AC Adapter
Stylus
Recovery DVD

Security Features:

Password Security
TPM Security Chip v.1.2
Computrace Theft Protection agent in BIOS
Contactless SmartCard Reader (ISO 14443 type A/B Compliant)

Energy Star:

Yes

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
EPEAT Gold

Warranty

Limited Warranty:

3 Year

Item Numbers

UNSPSC: 43211509
