Orion 22BL CCTV Monitor

Part Number: 22BL
Model: Parts
Add to My Shopping List Add to Compare
$2,409.65

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Number of Screens
1
Screen Size Class
22"
Viewable Screen Size
21.5"
Screen Mode
Full HD

Product Description:

  19.5INCH 1920X510 PIXELS BAR LCD MONITOR LED BACK LIGHT
Explore all Orion Parts Accessories
Add to Quote
Orion 22BL CCTV Monitor
Orion 22BL CCTV Monitor
Orion 22BL CCTV Monitor
Orion 22BL CCTV Monitor
Orion 22BL CCTV Monitor Orion 22BL CCTV Monitor Orion 22BL CCTV Monitor Orion 22BL CCTV Monitor

Orion Parts Accessory Model Overview

Products and parts from Orion.
Orion 22BL CCTV Monitor Overview

Full HD IPS Display

IPS (In-Plane Switching) technology highlights the performance of liquid crystal displays. Response times are shortened, color reproduction is improved, and users can view the screen at virtually any angle.

On-Screen Control

On-Screen Control puts a host of essential monitor settings into a handy window for quick, easy access. Volume, brightness, picture mode presets, Screen Split 2.0 and Dual Controller and more can now be adjusted with just a few clicks of the mouse, instead of hard buttons on the monitor.

Wall Mountable

This wall-mountable monitor provides the freedom to take the monitor off the desk and hang it on the wall, allowing you to expand your viewing options and save desktop space.

Technical Information
Number of Screens:
1
Screen Size Class:
22"
Viewable Screen Size:
21.5"
Screen Mode:
Full HD
Screen Surface:
Anti-glare
Panel Technology:
In-plane Switching (IPS) Technology
Response Time:
5 ms
Response Time Details:
5 ms GTG (Fast)
Aspect Ratio:
16:9
Pixel Pitch:
0.24795 mm x 0.24795 mm
Horizontal Viewing Angle:
178°
Vertical Viewing Angle:
178°
Features:
  • Reading Mode
  • Flicker-free
  • Smart Energy Saving
  • OnScreen Control
  • Super Resolution+
  • Black Stabilizer Technology
  • Crosshair
  • Dynamic Action Sync
  • Color Weakness Mode
Stand Adjustments:
  • Swivel
  • Height
  • Tilt
  • Pivot
Glass Hardness:
3H
Video
Maximum Resolution:
1920 x 1080
Maximum Resolution (HDMI):
1920x1080@75Hz
Standard Refresh Rate:
60 Hz
Color Supported:
16.7 Million Colors
Contrast Ratio:
1,000:1
Native Contrast Ratio:
1,000:1
Brightness:
250 Nit
Color Gamut:
72% NTSC (CIE 1931)
Audio
Number of Speakers:
2
Speakers:
Yes
Speaker Output Power:
2.40 W
Interfaces/Ports
HDMI:
Yes
HDMI Version:
1.4
USB:
Yes
Headphone:
Yes
DisplayPort:
Yes
DisplayPort Version:
1.2
Total Number of HDMI Ports:
1
Number of USB 3.0 Downstream Ports:
2
Number of USB 2.0 Upstream Ports:
1
Number of DisplayPorts:
1
Power Description
Input Voltage Range:
120V to 230V
Operating Power Consumption:
24.70 W
Maximum Power Consumption:
20 W
Physical Characteristics
VESA Mount Compatible:
Yes
VESA Mount Standard:
100 x 100
Height:
12"
Width:
20.1"
Depth:
2.3"
Height with Stand:
19.82"
Width with Stand:
20.06"
Depth with Stand:
9.45"
Weight (Approximate):
6.17 lb
Weight with Stand (Approximate):
10.80 lb
Miscellaneous
Package Contents:
  • 22BL450Y-B BL450Y Series Full HD IPS Desktop Monitor
  • Adapter
  • Power Cord
  • DisplayPort Cable
Certifications & Standards:
  • UL(cUL)
  • TUV-Type
  • TUV-GS
  • FCC-B
  • CE
  • ISO 9241-307
  • ISO13406-2
  • RoHS
  • CB
    • Country of Origin:
    Mexico
    UL Listed:
    Yes
    Environmentally Friendly:
    Yes
    Environmental Certification:
    • Electronic Product Environmental Assessment Tool Bronze (EPEAT Bronze)
    • ErP
    Energy Efficiency Compliance:
    Energy-related Products Directive (ErP)
    Environmental Compliance:
    • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
    • Restriction of Hazardous Substances (RoHS)
    Warranty
    Limited Warranty:
    3 Year
    Additional Warranty Information:
    3 Year Parts and Labor
    Item Numbers
    GTIN: 0719192629806, 0818260722606, 0818263095981, 0818275274503, 8806098742271
    UPC: 719192629806, 818260722606, 818263095981, 818275274503
    EAN: 0719192629806, 0818260722606, 0818263095981, 0818275274503, 8806098742271
    UNSPSC: 43211902
    Get help from a Barcoding Expert!

    What type of Barcode are you scanning?

    The Orion 22BL CCTV Monitor is also known as ORI-22BL
