Connectivity Technology:
Cable/Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 Databar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN-ISMN, Matrix 2of5, MSI/ Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal code:
- Chinese Post, Intelligent Mail Barcode, Korean Postal Authority code, POSTNET
2D:
- Aztec Code, Aztec Runes, Chinese Sensible code, Codablock F, Composite codes, Data matrix (ECC200), Passport MRZ (OCR-B), maxi Code (mode 2~5), MicroPDF417, MicroQR Code, PDF417, QR Code
Light Source:
LED
Scan Mode:
Trigger
Depth of Field:
Depth of field at code 39:
- 55 - 128 mm (0.127 mm) / 2.16 - 5.04 in (5 mil)
- 54 - 239 mm (0.254 mm) / 2.13 - 9.41 in (10 mil)
- 71 - 435 mm (0.508 mm) / 2.79 - 17.13 in (20 mil)
Depth of field at QR code:
- 62 - 113 mm (0.169 mm) / 2.44 - 4.45 in (6.7 mil)
- 24 - 252 mm (0.381 mm) / 0.94 - 9.92 in (15 mil)
Scan Pattern:
Area
Scanning Distance:
17.13"
Features:
- Notification LED
- Vibration
- Scan Button
- Ergonomic Design
Number of Keys:
2
Field of View (Horizontal):
38°
Field of View (Vertical):
29°
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Maximum Ambient Light:
100000 lux
Drop Specification:
- 1.5 m / 5 ft drop onto concrete surface
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Image Sensor Resolution:
640 x 480
Illumination Type:
LED
Illumination Color:
White
