Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
1D:
- JAN/UPC/EAN incl. add on, Codabar/NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN-128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISMN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey
Postal code:
- Chinese Post, Korean Postal Authority code
Light Source:
Laser
Scan Rate:
100 scan/s
Scan Mode:
Trigger
Depth of Field:
Depth of field At PCS 0.9, Code 39:
- 40 - 500 mm / 1.57 - 19.69 in (1.0 mm / 39 mil)
- 20 - 350 mm / 0.79 - 13.78 in (0.5 mm / 20 mil)
- 20 - 200 mm / 0.79 - 7.87 in (0.25 mm / 10 mil)
- 20 - 100 mm / 0.79 - 3.94 in (0.15 mm / 6 mil)
- 30 - 70 mm / 1.18 - 2.76 in (0.127 mm / 5 mil)
Scan Pattern:
Bi-directional
Scanning Distance:
19.69"
Features:
- Notification LED
- Vibration
- Scan Button
Number of Keys:
1
Reading Angle (Skew):
50°
Reading Angle (Pitch):
35°
Maximum Ambient Light:
50000 lux
Drop Specification:
- 1.5 m / 5 ft drop onto concrete surface
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
39 mil
