Connectivity Technology:
Cable/Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- UPC/EAN/JAN (standard, composite, addon), Code 39, Codabar (NW7), Industrial 2 of 5, Interleaved 2 of 5, Code 128, Code 93, IATA, MSI/Plessey, UK/Plessey, Telepen, Code 11, Matrix 2 of 5, JPN, GS1-Databar (Limited, Expanded, Composite), GS1-128 (standard, composite)
2D:
- PDF417, micro PDF417, Codablock F, QR Code, Micro QR Code, Data Matrix (ECC 000-140 & ECC 200), Aztec Code, Aztec Runes, Chinese Sensible Code, Maxicode
POSTAL CODES:
- Chinese Post Matrix 2 of 5, Korean Postal Authority, Intelligent Mail Barcode, Postnet
Light Source:
LED
Image Sensor Type:
- CMOS
- Imager
Scan Mode:
Trigger
Depth of Field:
DEPTH OF FIELD:
- Code 39 at 5 mils (0.127 mm): 3.54 - 4.33 in (90 - 110 mm)
- Code 39 at 10 mils (0.254 mm): 2.56 - 7.28 in (65 - 185 mm),
- Code 39 at 20 mils (0.508 mm): 2.56 - 10.24 in (65 - 260 mm)
- Code 128 at 7.87 mils (0.20 mm): 3.35 - 6.50 in (85 - 165 mm)
- UPC at 13 mils (0.33 mm): 2.17 - 7.68 in (55 - 195 mm)
- PDF417 at 6.65 mils (0.169 mm): 3.35 - 5.31 in (85 - 135 mm)
- PDF417 at 10 mils (0.254 mm): 2.56 - 7.09 in (65 - 180 mm)
- QR Code at 8.35 mils (0.212 mm): 3.54 - 4.33 in (90 - 110 mm)
- QR Code at 15 mils (0.381 mm): 2.17 - 7.09 in (55 - 180 mm)
- Data Matrix at 10 mils (0.254 mm): 3.35 - 5.31 in (85 - 135 mm)
Scanning Distance:
10.24"
Features:
- Vibration
- Notification LED
Number of Keys:
2
Field of View (Horizontal):
41°
Field of View (Vertical):
26°
Reading Angle (Skew):
50°
Reading Angle (Pitch):
50°
Reading Angle (Roll):
180°
Motion Tolerance:
78.74 in/s
Maximum Ambient Light:
100000 lux
Drop Specification:
- 5 ft (1.5 m) onto to concrete
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
6.6 mil
Maximum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
752 x 480
Illumination Type:
LED
