Connectivity Technology:
Cable/Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- UPC-A, UPC-A Add-on, UPC-E, UPC-E Add-on, EAN-13, EAN-13 add-on, EAN-8, EAN-8 Addon, JAN-8, JAN-13, Codabar / NW-7, Code 11, Code 39, Code 93, Code 128, GS1 DataBar, GS1 DataBar Limited, GS1 DataBar Expanded, Composite GS1-DataBar, Composite GS1-128, Composite EAN, Composite UPC, IATA, Industrial 2of5, Interleaved 2of5, Matrix 2of5, MSI/Plessey, UK/Plessey, S-Code, Telepen, Tri-Optic
Postal Code:
- Chinese Post, Korean Postal Authority code
2D:
- Aztec Code, Codablock F, Data Matrix (ECC 200), Maxi Code (mode 2 to 5), MicroPDF417, Micro QR Code, PDF417, QR Code, Chinese Sensible Code
Light Source:
LED
Image Sensor Type:
Imager
Depth of Field:
Depth of field at code 39:
- 60 - 150 mm (0.127 mm) / 2.36 - 5.90 in (5 mil)
- 70 - 205 mm (0.254 mm) / 2.76 - 8.07 in (10 mil)
- 80 - 390 mm (0.508 mm) / 3.15 - 15.35 in (20 mil)
Depth of field at Code 128:
- 80 - 165 mm (0.2 mm) / 3.15 - 6.50 in (7.87 mil)
Depth of field at UPC:
- 65 - 260 mm (1.33 mm) / 2.56 - 10.24 in (52.36 mil)
Depth of field at PDF417:
- 65 - 125 mm (0.169 mm) / 2.56 - 4.92 in (6.65 mil)
- 50 - 180 mm (0.254 mm) / 1.97 - 7.09 in (10 mil)
Depth of field at QR Code:
- 70 - 95 mm (0.169 mm) / 2.76 - 3.74 in (6.65 mil)
- 35 - 225 mm (0.381 mm) / 1.38 - 8.86 in (15 mil)
Depth of field at Data Matrix:
- 60 - 130 mm (0.212 mm) / 2.36 - 5.12 in (8.35 mil)
- 50 - 150 mm (0.254 mm) / 1.97 - 5.91 in (10 mil)
Scan Pattern:
Area
Scanning Distance:
15.35"
Features:
- Notification LED
- Vibration
- Scan Button
Number of Keys:
2
Field of View (Horizontal):
38°
Field of View (Vertical):
29°
Reading Angle (Skew):
70°
Reading Angle (Pitch):
70°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
- 201.5 m / 5 ft drop onto concrete surface
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
20 mil
Minimum Element Resolution (DataMatrix):
8.3 mil
Maximum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
6.6 mil
Maximum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
640 x 480
