Opticon – Barcode Scanner – Scanner with Cable and Stand

Part Number: OPL-9815-02
Model: Parts
3-year Premium Plus ($54.70)
No, stay at premium support package
Add to My Shopping List Add to Compare
$389.51

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wireless
Scanning Capability
1D
Barcode Symbology Supported
1D: JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN -128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/PlesseyPostal Codes: Chinese Post, Korean Postal Authority code
Light Source
Laser

Product Description:

  OPL-9815 1D LASER, BLUETOOTH, GPS, 1MB MEMORY, BATTERY & WRIST STRAP INCLUDED, CRADLE SOLD SEPARATELY
Explore all Opticon Parts Accessories
Add to Quote
Opticon OPL-9815-02 Barcode Scanner
Opticon OPL-9815-02 Barcode Scanner
Opticon OPL-9815-02 Barcode Scanner
Opticon OPL-9815-02 Barcode Scanner Opticon OPL-9815-02 Barcode Scanner Opticon OPL-9815-02 Barcode Scanner

Opticon Parts Accessory Model Overview

Products and parts from Opticon.
Opticon OPL-9815-02 Barcode Scanner Overview

Bluetooth Laser Barcode Scanner with GPS, Screen, and 18-key Operation

The OPL-9815, a Bluetooth™ laser scanner from Opticon, features GPS, a real-time clock and 18-key operation for data-capture applications that require location and time stamps, as well as data entry. The OPL-9815 is perfect for inventory, logistics, warehouse and retail applications. Since the OPL-9815 is programmable, channel partners can create custom solutions around the OPL-9815 using the free SDK from Opticon.

The OPL-9815 can transmit data via Bluetooth™ connection, or store data onboard for later transfer via IrDA through a charging cradle (sold separately). The charging cradle is available with a serial, modem or GSM interface. OPL-9815 product highlights include:

  • Wireless laser barcode scanner with GPS - featuring 100 scans per second speed
  • HID or SPP Bluetooth™ transmission of data to a host
  • 512KB of flash ROM and 512KB of RAM
  • 18-key operation
  • Monochrome 112x64 pixel screen with back light
  • Programmable - free Opticon SDK enables solution providers to create customized scanning solutions
  • Compact size and weight - 1.7"W x 5.5"L x 0.9"D; 3.8 oz
  • Rechargeable Lithium-Ion battery
  • Minimum standby time is 48 hours
  • IP54 enclosure rating; withstands 5-foot drop to concrete
  • Data can also be transmitted to host via IrDA when OPL-9815 is placed in charging cradle
  • Two-year warranty
Technical Information
Connectivity Technology:
Wireless
Scanning Capability:
1D
Barcode Symbology Supported:

1D:

  • JAN/UPC/EAN incl. add on, Codabar/ NW-7, Code 11, Code 39, Code 93, Code 128, GS1-128 (EAN -128), GS1 DataBar (RSS), IATA, Industrial 2of5, Interleaved 2of5, ISBN-ISSN, Matrix 2of5, MSI/Plessey, S-Code, Telepen, Tri-Optic, UK/Plessey

Postal Codes:

  • Chinese Post, Korean Postal Authority code
Light Source:
Laser
Scan Rate:
100 scan/s
Depth of Field:
  • 39 mil (1.0 mm) 2.36 - 11.81 in (60 - 300 mm)
  • 20 mil (0.5 mm) 1.38 - 8.27 in (35 - 210 mm)
  • 10 mil (0.25 mm) 1.38 - 4.72 in (35 - 120 mm)
  • 6 mil (0.15 mm) 1.38 - 2.76 in (35 - 70 mm)
Scanning Distance:
11.81"
Features:
GPS
Display Screen:
Yes
Number of Keys:
18
Keypad Type:
Alphanumeric
Reading Angle (Skew):
50°
Reading Angle (Pitch):
25°
Maximum Ambient Light:
50000 lux
Drop Specification:

5 ft (1.5 m) drop onto concrete surface

Minimum Element Resolution (Code 39):
6 mil
Maximum Element Resolution (Code 39):
39 mil
Memory
Standard Memory:
512 MB
Flash Memory:
1 MB
Processor & Chipset
Processor Speed:
96 MHz
Network & Communication
Bluetooth:
Yes
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Capacity:
1100 mAh
Maximum Battery Run Time:
72 Hour
Environmental Conditions
Operating Temperature:
32°F (0°C) to 104°F (40°C)
Storage Temperature:
-4°F (-20°C) to 140°F (60°C)
Humidity (Non-condensing):
20% to 85%
Physical Characteristics
Rugged:
Yes
Color Family:
Black
Product Color:
Black
Product Material:
Acrylonitrile Butadiene Styrene (ABS)
Height:
5.5"
Width:
1.7"
Depth:
0.9"
Weight (Approximate):
4.10 oz
Miscellaneous
Ingress Protection (IP) Rating:
IP54
Application/Usage:
  • Logistics
  • Warehouse
  • Retail
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
2 Year
Item Numbers
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Opticon OPL-9815-02 Barcode Scanner is also known as OPL-9815-02
