Opticon C37 – Barcode Scanner – Cable Only

Part Number: C37BR1-00
Model: C37
3-year Premium Plus ($54.70)
No, stay at premium support package
Add to My Shopping List Add to Compare
$67.94

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Scanner Type
CCD, Imager

Product Description:

  C37 CCD Scanner, RS232 (Black)
Explore all Opticon C37 Barcode Scanners
Add to Quote
Opticon C37BR1-00 Barcode Scanner
Opticon C37BR1-00 Barcode Scanner
Opticon C37BR1-00 Barcode Scanner
Opticon C37BR1-00 Barcode Scanner
Opticon C37BR1-00 Barcode Scanner Opticon C37BR1-00 Barcode Scanner Opticon C37BR1-00 Barcode Scanner Opticon C37BR1-00 Barcode Scanner
Full specifications (PDF)

Opticon C37 Barcode Scanner Model Overview

The Opticon C37 Barcode CCD Scanner is a robust and versatile cabled device, perfect for enhancing efficiency in inventory management and retail environments. With multiple interface options including RS232, Keyboard Wedge, and USB, this scanner adapts to your needs seamlessly. Achieving a scan rate of 200 scans per second through its advanced CCD linear sensor, the C37 ensures quick and accurate barcode reading. Its durable design is backed by a protection rate of IP42, making it reliable in diverse working conditions while maintaining exceptional performance.


Key Features

  • High scan rate: 200 scans/sec for efficient performance.
  • Multiple interfaces: RS232, USB for versatile connectivity.
  • Durable design: Built to withstand drops and high humidity, with IP42 protection.
  • Easy operation: Manual and auto-trigger options for scanning convenience.
  • Wide temperature range: Operates in environments from 0 to 50 °C (32 to 122 °F).

Specifications

  • Dimensions: 75 x 150 x 53 mm (2.95 x 5.91 x 2.09 in)
  • Weight: 90 g (3.2 oz) excluding cable
  • Power Supply: 100-240V/0.5A, 50/60 Hz
  • Operating Temperature: 0 to 50 °C / -20 to 60 °C (storage)
  • Humidity: 5 - 95% (non-condensing)
  • Drop Test: 1.5 m / 5 ft onto concrete
  • Light source: 630 nm red LED
  • Supported Symbologies: JAN/UPC/EAN, Code 39, Code 128, and more
Opticon C37BR1-00 Barcode Scanner Overview

The C-37 CCD scanner is a durable handheld barcode reader with a wide optical window and a strong scan engine. The scanner can operate at a speed of up to 200 scans per second and fits comfortably in anyone's hand. The scanner is available in black or white and is the perfect scanner for your counter.

This ergonomically shaped C-37 is a CCD scanner that works on any counter, desk, or surface. With 200 scans a second it is also a rapid scanner with an auto-scan option. Combine that with the optional stand and you have a hands free scanning solution. This scanner is available in black and white. With an IP rating of IP42, it is also resistant to drops up to 1.5 meters.

This cabled scanner comes with RS-232, keyboard wedge, or USB interface. This device is easily programmable to suit your application.

A few highlights why the C-37 is the next scanner you should buy:

  • 200 scans per second
  • Lightweight and ergonomic
  • Sleek design
  • Black and white choice


Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:

1D:

  • AN/UPC/EAN incl. add on
  • Codabar/NW-7
  • Code 11
  • Code 39
  • Code 93
  • Code 128
  • GS1-128 (EAN-128)
  • GS1 Databar (RSS)
  • IATA
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • ISBN-ISSM-ISSN
  • Matrix 2 of 5
  • MSI/Plessey
  • S-Code
  • Telepen
  • Tri-Optic
  • UK/Plesse

Postal Code:

  • Chinese Post
  • Korean Postal Authority Code


Light Source:
LED
Image Sensor Type:
  • CCD
  • Imager
Scan Rate:
200 scan/s
Scan Mode:
Trigger
Depth of Field:
  • 0 - 15 mm / 0 - 0.59 in @ code 39
Scan Pattern:
Linear
Scanner Range:
Standard Range
Scanning Distance:
0.59"
Features:
  • Notification LED
  • Vibration
  • Ergonomic Design
Number of Keys:
1
Cable Type Included:
Serial
Reading Angle (Skew):
70°
Reading Angle (Pitch):
30°
Maximum Ambient Light:
10000 lux
Drop Specification:
  • 1.5 m / 5 ft drop onto concrete surface
Interfaces/Ports
Host Interface:
  • Serial
  • USB
  • Keyboard Wedge
Environmental Conditions
Operating Temperature:
32°F (0°C) to 122°F (50°C)
Storage Temperature:
-4°F (-20°C) to 140°F (60°C)
Humidity (Non-condensing):
5% to 95%
Physical Characteristics
Form Factor:
Handheld
Rugged:
Yes
Color Family:
Black
Product Color:
Black
Product Material:
Acrylonitrile Butadiene Styrene (ABS)
Durability:
  • Dust Resistant
  • Water Resistant
Height:
3"
Width:
2.1"
Depth:
5.9"
Weight (Approximate):
3.17 oz
Miscellaneous
Package Contents:
  • C-37 Barcode Scanner
  • RS232 Cable
Ingress Protection (IP) Rating:
IP42
Application/Usage:
  • Healthcare
  • Retail
  • Self-checkout
  • Commercial Service
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty:
2 Year
Item Numbers
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Opticon C37BR1-00 Barcode Scanner is also known as OPT-C37BR100 or C37BR100.
