Opengear NP-OM1208-L Console & Device Servers
Part Number:
NP-OM1208-L
Model:
Opengear Console & Device Servers Model Overview
Find Opengear’s serial console and out-of-band management devices
Opengear NP-OM1208-L Console & Device Servers Overview
Opengear OM appliances are NetOps Console Servers - Network Management appliances that combine the capabilities of a SmartOOB™ Console Server with the flexibility of NetOps Automation.
The compact OM1200 appliance is designed specifically for secure edge deployments, used in combination with Lighthouse Management Software. As a key component of Opengear's Network Resilience Platform, it provides the Presence & Proximity at every location that supports emerging requirements in Network Management and Automation.
Features
- 8 Serial and 8 Ethernet port combinations
- Global LTE interface (optional)
- x86 platform; embedded physical security
- Python runtime, Docker container support
Technical Information
Processor & Chipset
Processor Manufacturer:
AMD
Processor Speed:
1.40 GHz
Memory
Memory Technology:
DRAM
Maximum Memory Supported:
4 GB
Media & Performance
Media Type Supported:
- Twisted Pair
- Optical Fiber
I/O Expansions
Total Number of Expansion Slots:
2
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Network Standard:
- 10/100/1000Base-T
- 1000Base-X
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Serial Port:
Yes
Management Port:
Yes
Total Number of Network Ports:
8
Number of Network (RJ-45) Ports:
8
Number of USB Ports:
4
Number of Serial Ports:
8
Power Description
Input Voltage:
- 120 V AC
- 230 V AC
Power Consumption:
25 W
Physical Characteristics
Form Factor:
- Rack-mountable
- Desktop
Height:
1.7"
Width:
8.7"
Depth:
6.7"
Weight (Approximate):
2.20 lb
Miscellaneous
Package Contents:
- OM1208-8E-L Device Server
- 1 x Rack Mount Kit
- 1 x DB9F-RJ45 Crossover
- 4 x Rubber Feet
- 1 x 12V Global Power Supply
- Quick Start Flyer
- 2 x Cellular Antennas
- 1 x Cellular Antenna Extender with Magnetic base
Certifications & Standards:
- EN 55022:2010
- CISPR 22:2008
- FCC Part 15 Subpart B:2015
- ICES-003 Issue 5 (2014)
- AS/NZS CISPR 22:2009+A1:2010
- EN 61000-3-2:2006/A2:2009
- EN 61000-3-3:2008
- EN 55024:2010
- CISPR 24:2010
- EN 61000-4-2:2009
- EN 61000-4-3:2006+A2:2010
- EN 61000-4-4:2004+A1:2010
- EN 61000-4-5:2006
- EN 61000-4-6:2009
- EN 61000-4-8:2010
- EN 61000-4-11:2004
- CE
- UL 1950
- TUV
- C-Tick
- NERC CIP
- FIPS 140-2 validated module Certificate #2473
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
4 Year
Item Numbers
UNSPSC:
43222625
