Opengear ACM7004-2-LMP Network Management Devices

Part Number: ACM7004-2-LMP
Model:
Add to My Shopping List Add to Compare
$1,639.52

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Form Factor
DesktopRack MountRail-mountable
Height
1.4"
Width
5.1"
Depth
4.7"

Product Description:

  Network Management Devices, Opengear, 4 Serial Ports, Cisco Straight Pinout
Explore all Opengear Console & Device Servers
Add to Quote
Opengear ACM7004-2-LMP Network Management Devices
Opengear ACM7004-2-LMP Network Management Devices
Opengear ACM7004-2-LMP Network Management Devices Opengear ACM7004-2-LMP Network Management Devices

Opengear Console & Device Servers Model Overview

Find Opengear’s serial console and out-of-band management devices
Physical Characteristics
Form Factor:
  • Desktop
  • Rack Mount
  • Rail-mountable
Height:
1.4"
Width:
5.1"
Depth:
4.7"
Weight (Approximate):
1.32 lb
Miscellaneous
Package Contents:
  • Resilience Gateway ACM7000-LMx With Smart OOB and Failover to Cellular
  • External Rack Mount Tab
  • Black Terminal Block
  • 2 x 4G LTE Blade Antennas
  • Dual SIM Holder
  • DB9F-RJ45 Adapter
  • 4 x Rubber Feet
  • Quick Start Guide
Additional Information:
Console Ports: 4 x RJ45 RS-232 Cisco straight pinout console ports

Ethernet Ports: 2 x 10/100/1000 Ethernet

Serial Ports: Cisco straight 50 to 230,400 bps

USB Ports: 4 x USB 2.0 Console Ports

Remote Access: Integrated 4G LTE Cellular Card, Dual Ethernet, aggregation & redundancy, Automatic Network Failover, Easy browser UI, IPv6

I/O Ports:
  • 2 x TTL level Digital I/O ports (DIO) 5V DC max @ 20mA (supports external water /smoke / motion dry contact sensors)
  • 2 x High Voltage Digital Outputs (HVDO) 5-30V DC@ 100mA (drives relays, alarms, etc.)
Console Management
  • Built-in web terminal
  • SSH direct to consoles
  • Optional console keystroke logging
  • Alert on cable disconnects, text pattern match and more
  • Inline power control
  • Multiple concurrent sessions
Power Requirements
  • Power Adapter: 110-240V AC to 12V DC external power adapter
  • Power Consumption: Less than 11.5W
Form Factor: Compact

Memory & CPU
  • CPU: 800 MHz Armada 370 ARMv7 SoC (Marvell 88F6W11)
  • Memory
    • 256 MB DDR3 SDRAM
    • 32 MB Embedded NOR Flash
  • Internal Storage: 4 GB NAND Flash
Environmental
  • Operating Temperature -25°C to +60°C, -13°F to +140°F
  • Storage Temperature -40°C to +75°C, -40°F to +167°F
  • Humidity 5% to 90%
  • Environmental Monitoring Internal temperature sensor and external serial EMD5000 device supports physical, smoke, water leak, vibration sensors
Security, Encryption & Authentication
  • SSH
  • AAA - TACACS+, RADIUS, Active Directory/OpenLDAP, Kerberos, with local fallback
  • FIPS-140-2 compliant Open SSL Module
  • Two factor authentication via remote AAA
  • Strong ciphers - AES encryption
  • Configurable stateful firewall
  • Cisco-compatible IPsec
  • OpenVPN
Automation & Scalability
  • ZTP, Lighthouse
  • RESTful API, programmable and extensible
  • Auto-Response, SNMP, LLDP, NTP
Application/Usage:
Remote Management
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
4 Year
Item Numbers
GTIN: 0843295102406
UPC: 843295102406
EAN: 0843295102406
UNSPSC: 43222634
