Newland FR2780 – Barcode Scanner – Cable Only

Part Number: NLS-FR2780-20
Model: FR2780 2D Desktop Scanner
3-year Premium Plus ($54.70)
No, stay at premium support package
Add to My Shopping List Add to Compare
$167.69

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D2D
Barcode Symbology Supported
1D: All major 1D symbologies 2D: QR Code Data Matrix Aztec Micro PDF Micro QR PDF417
Image Sensor Type
CMOS

Product Description:

  Barcode Scanners, Newland FR2780, Retail/Phone Screen 2D Desktop Scanner with USB cable, 2.7 m/s Motion Tolerance, CPU Decoding, White
Explore all Newland FR27 Barcode Scanners
Add to Quote
Newland NLS-FR2780-20 Barcode Scanner
Newland NLS-FR2780-20 Barcode Scanner
Newland NLS-FR2780-20 Barcode Scanner
Newland NLS-FR2780-20 Barcode Scanner Newland NLS-FR2780-20 Barcode Scanner Newland NLS-FR2780-20 Barcode Scanner
Full specifications (PDF)

Newland FR27 Barcode Scanner Model Overview

Newland AIDC presents the NLS-FR27 Fixed Mount Barcode Scanner, designed to simplify your scanning experience. Featuring the cutting-edge UIMG® technology, this scanner easily decodes even the most challenging barcodes, including soiled or wrinkled labels. Its compact, lightweight design allows for convenient positioning in tight spaces, making it ideal for retail and small workstations. With superior motion tolerance and a large field of view, the FR27 enhances user efficiency and satisfaction during high-volume scanning operations.
Key features:
  • World-leading UIMG® Technology: Effortlessly scans poor-quality barcodes.
  • Space-saving Design: Perfect for limited counter space at retail points.
  • On-screen Barcode Capture: Optimized for reading digital barcodes under protective film.
  • Superior Motion Tolerance: Works effectively at speeds up to 2.7m/s with a large field of view.

Specifications:
  • Image Sensor: 640*480 CMOS
  • Illumination: White LED
  • Operating Voltage: 5VDC±5%
  • Power Consumption: 698mW (typical)
  • Dimensions: 66.3 (W) × 76.3 (D) × 38 (H) mm
  • Weight: 120g
  • Operating Temperature: -20°C to 60°C
  • Humidity: 5% to 95% (non-condensing)
  • Drop Resistance: 1.5m
  • Protection Rating: IP42
Newland NLS-FR2780-20 Barcode Scanner Overview

FR27 Urchin 2D CMOS Desktop Area Imager Reader, White color with 1,5 mtr. direct USB cable (NLS-FR2780-W-20).

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
1D:
  • All major 1D symbologies
2D:
  • QR Code
  • Data Matrix
  • Aztec
  • Micro PDF
  • Micro QR
  • PDF417
Image Sensor Type:
CMOS
Scanning Distance:
4.13"
Cable Type Included:
USB
Field of View (Horizontal):
68°
Field of View (Vertical):
51°
Reading Angle (Skew):
75°
Reading Angle (Pitch):
75°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
1.5m Drop
Minimum Print Contrast:
20%
Maximum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (PDF417):
6.7 mil
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Form Factor:
Desktop
Color Family:
White
Product Color:
White
Height:
1.5"
Width:
2.6"
Depth:
3"
Weight (Approximate):
4.23 oz
Miscellaneous
Ingress Protection (IP) Rating:
IP42
Application/Usage:
  • Kiosk
  • Transportation
  • Hospitality
  • Retail
Country of Origin:
China
Item Numbers
UNSPSC: 43211701
