Device Supported:
- Control Panel
- Smoke Detector
Newcastle Systems B201 Battery
Part Number:
B201
Model:
Accessories
Newcastle Systems Accessories Accessory Model Overview
Newcastle Systems' line of accessories can be integrated with any product series in seconds to create a highly functional mobile workstation that is customized to your specific application.
Newcastle Systems B201 Battery Overview
The B201 provides a single powered initiating device circuit. The module supports compatible 12 V 2-wire smoke detectors. The B201 is suitable for connecting powered, 2-wire fire or burglary devices. Use with a D132A Smoke Detector Reversing Relay Module for smoke detectors with integrated sounders.
Functions
The module connects to the control panel inputs. Terminals A and COM are a direct connection (passthru) point, and terminals B and PWR are a powered loop.
The powered loop uses a 1.8 kΩ EOL for supervision.
Technical Information
Physical Characteristics
Height:
1.4"
Width:
1.4"
Depth:
1.5"
Miscellaneous
Package Contents:
- B201 2-Wire Powered Loop
- 1 x 1.8 kΩ EOL Resistors
- 2 x Standoffs
- 1 x Installation Manual
Additional Information:
Country of origin: China. Country of origin is subject to change.
Compatibility:
Bosch D132A Smoke Detector
Country of Origin:
China
Item Numbers
UNSPSC:
46171600
Get help from a Barcoding Expert!
The Newcastle Systems B201 Battery is also known as
BOS-B201
