NETGEAR WAX620PA-100NAS Wireless Router

Part Number: WAX620PA-100NAS
Model: Parts
$206.99
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11 a/b/g/n/ac/ax/i
Network Band
Dual Band
Frequency Band
2.40 GHz5 GHz
Indoor/Outdoor
Indoor

Product Description:

  Netgear WAX620 Dual Band 802.11ax 3.60 Gbit/s Wireless Access Point, Indoor, 2.40 GHz, 5 GHz, Internal, MIMO Technology, 1 x Network (RJ-45), 2.5 Gigabit Ethernet, PoE Ports, Ceiling Mountable, Wall Mountable
Technical Information
Wireless LAN Standard:
IEEE 802.11 a/b/g/n/ac/ax/i
Network Band:
Dual Band
Frequency Band:
  • 2.40 GHz
  • 5 GHz
Indoor/Outdoor:
Indoor
Wireless Transmission Speed:
3.60 Gbit/s
MIMO Technology:
Yes
Beamforming Technology:
Yes
Data Encryption:
Yes
Encryption Standard:
  • WPA
  • WPA2
  • WPA3
  • WPA2-ENT
  • WPA-ENT
Interfaces/Ports
Ethernet Technology:
2.5 Gigabit Ethernet
Number of Network (RJ-45) Ports:
1
PoE PD Port:
Yes
Network & Communication
Wi-Fi Generation:
Wi-Fi 6
Physical Characteristics
Form Factor:
  • Ceiling Mountable
  • Wall Mountable
Antenna Form Factor:
Internal
Height:
1.4"
Width:
8.1"
Depth:
8.1"
Weight (Approximate):
1.73 lb
Miscellaneous
Package Contents:
  • WAX620 Wireless Access Point
  • Wall/ceiling Mount Kit
  • Installation Guide
  • US - Power Adapter
Certifications & Standards:
  • IEEE 802.3af
  • IEEE 802.3at
Country of Origin:
Taiwan
Environmentally Friendly:
Yes
Energy Efficiency Compliance:
Energy-related Products Directive (ErP)
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
  • Registration, Evaluation, Authorization and Restriction of Chemicals (REACH)
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0606449154528
UPC: 606449154528
EAN: 0606449154528
UNSPSC: 43222631

Frequently Asked Questions

The NETGEAR WAX620PA is a dual-band 802.11ax wireless access point that operates on both 2.4 GHz and 5 GHz frequencies. This Wi-Fi 6 standard delivers up to 3.60 Gbit/s throughput, making it suitable for high-density warehouse and logistics environments requiring reliable connectivity across multiple devices and access points.

Yes, the WAX620PA features PoE (Power over Ethernet) ports, allowing you to power and connect the access point using a single Ethernet cable. This simplifies installation in ceiling and wall-mounted deployments common in warehouses and distribution centers, reducing the need for separate power infrastructure.

The NETGEAR WAX620PA supports both ceiling and wall mounting, providing flexible deployment options for indoor warehouse and logistics facilities. The dual mounting capability allows your IT team to optimize coverage and placement based on your facility's layout and RF requirements.

The WAX620PA includes a 2.5 Gigabit Ethernet port (RJ-45) and PoE ports for robust wired connectivity. This high-speed wired connection ensures reliable backhaul to your core network infrastructure, critical for real-time barcode scanning and mobile computer operations in logistics environments.

Yes, the WAX620PA is equipped with MIMO (Multiple-Input Multiple-Output) technology, which improves wireless performance and range by using multiple antennas for simultaneous data transmission. This is particularly valuable in warehouse settings where you need consistent coverage for barcode scanners and mobile devices across large areas.

The NETGEAR WAX620PA is specifically designed as an indoor access point, making it well-suited for warehouse, distribution center, and logistics facility deployments. We offer this model to support the connectivity needs of mobile computers and scanning equipment in professional AIDC environments—contact us today to discuss your facility's wireless infrastructure requirements.
