Features:
Fanless
NETGEAR MS105-100NAS Data Networking
Part Number:
MS105-100NAS
Model:
Parts
Technical Information
Interfaces/Ports
Total Number of Network Ports:
5
Network (RJ-45):
Yes
Port/Expansion Slot Details:
5 x 2.5 Gigabit Ethernet Network
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
2.5 Gigabit Ethernet
Network Technology:
2.5GBase-T
Network & Communication
Layer Supported:
2
Networking Standards:
- IEEE 802.3az
- IEEE 802.3
- IEEE 802.3ab
- IEEE 802.3u
- IEEE 802.1p
- IEEE 802.3x
Management & Protocols
Manageable:
No
Power Description
Input Voltage:
12 V DC
Power Source:
- Power Adapter
- DC
Power Consumption:
9.24 W
Physical Characteristics
Product Material:
Metal
Form Factor:
- Desktop
- Wall Mountable
- Enclosure
Height:
1.1"
Width:
6.2"
Depth:
4"
Weight (Approximate):
1.06 lb
Miscellaneous
Package Contents:
- 5-Port Multi-Gigabit (2.5G) Ethernet Unmanaged Switch
- Power Adapter
- Wall Installation Kit
- Rubber Feet
- Installation Guide
Application/Usage:
Business
Country of Origin:
Thailand
Warranty
Limited Warranty:
Lifetime
Item Numbers
GTIN:
0606449160109
UPC:
606449160109
EAN:
0606449160109
UNSPSC:
43222612
Frequently Asked Questions
What are the key specifications of the NETGEAR MS105-100NAS switch?
The NETGEAR MS105-100NAS is a 5-port multi-gigabit unmanaged switch supporting 2.5 Gigabit Ethernet connectivity with 2.5GBase-T technology. It operates at 9.24 W power consumption, supports Layer 2 networking, and is available as a desktop or wall-mountable unit. The switch comes with a lifetime limited warranty and is backed by NETGEAR's reliability standards.
Is the NETGEAR MS105-100NAS suitable for warehouse or logistics environments?
Yes, the MS105-100NAS is designed for data networking in professional environments including warehouse and logistics operations. Its unmanaged architecture provides plug-and-play deployment without complex configuration, making it ideal for facilities that need straightforward network expansion without IT overhead. The device's compact form factor supports both desktop and wall-mounted installation for flexible deployment.
What type of cable connections does the NETGEAR MS105-100NAS support?
The NETGEAR MS105-100NAS supports twisted pair cabling for 2.5 Gigabit Ethernet connections across all five ports. The switch features auto MDI/MDIX adjustment, which automatically detects and adapts to standard or crossover cables, simplifying installation and reducing compatibility issues in mixed network environments.
What are the operating conditions for the NETGEAR MS105-100NAS?
The NETGEAR MS105-100NAS operates in temperatures from 32 to 130°F (0 to 50°C) and supports operating humidity levels from 10% to 90% RH non-condensing. For storage, the device can be maintained in temperatures ranging from -14 to 158°F (-10 to 70°C) with storage humidity from 5% to 90% RH non-condensing, ensuring reliability across varied facility conditions.
How does the NETGEAR MS105-100NAS handle network traffic and performance?
The MS105-100NAS uses store-and-forward transmission methodology with per-port Link/Activity/Speed LED indicators for network monitoring. It features a 2K MAC address table with automatic learning capabilities and includes QoS support with 4 queues in strict mode, enabling prioritization of critical warehouse and logistics traffic. The device provides dedicated bandwidth per port for consistent multi-gigabit performance.
What warranty and support options are available for the NETGEAR MS105-100NAS?
The NETGEAR MS105-100NAS includes a lifetime limited warranty, providing long-term protection for your networking investment. We offer this switch through our comprehensive AIDC product portfolio, and our team can help you integrate it into your warehouse or logistics infrastructure. Contact us today at barcodesinc.com for warranty details, technical support, and deployment assistance.
The NETGEAR MS105-100NAS Data Networking is also known as
NTG-MS105100NAS
