NCR P-7772-CX7-I5-USB-IO Accessory
NCR Parts Accessory Model Overview
Frequently Asked Questions
What processor options are available for the NCR P-7772-CX7-I5-USB-IO?
The NCR CX7 series offers multiple processor options including Intel Core i5-6500TE with vPro, Intel Core i3-6100TE, and Intel Celeron G3900TE. These scalable processor options allow you to choose the performance level that best fits your retail or hospitality operation's requirements.
How many USB ports does this NCR CX7 terminal have and what types?
The NCR P-7772-CX7-I5-USB-IO features 11 total USB ports with diverse power configurations: 7 powered USB ports at 12V, 1 powered USB port at 24V for printers, and 3 standard 5V USB ports (including 2 USB 3.0 rear ports and 1 USB 2.0 front port). This extensive connectivity supports multiple peripherals including barcode scanners, receipt printers, and payment devices simultaneously.
What display specifications does the NCR CX7 POS terminal include?
The NCR CX7 includes a 15.6-inch projected capacitive touchscreen with a 16:9 aspect ratio, providing an intuitive interface for both operator and customer interactions. The responsive touchscreen is designed for high-traffic retail and hospitality environments.
What connectivity options are included beyond USB ports?
Beyond USB connectivity, the NCR CX7 provides 4 powered serial ports, 2 DisplayPorts, 1 VGA port, 1 PS/2 port, 1 cash drawer port, and 1 amplified audio port. It also includes a 10/100/1000MB Ethernet LAN connection for reliable network integration in your retail operation.
Does this model include an integrated Magnetic Stripe Reader?
The NCR CX7 series offers model variations that include a Magnetic Stripe Reader (MSR) option. The USB-IO configuration you're viewing is part of a flexible product line where MSR capability can be selected based on your payment processing requirements.
What are the physical dimensions and weight of the NCR P-7772-CX7-I5-USB-IO?
The terminal measures 11.8 inches wide by 11.91 inches deep with a height of 4.28 inches (rear I/O option), and weighs 13.85 lbs for the terminal alone. With optional UPS backup, the total weight increases to 20.55 lbs, making it suitable for countertop deployment in retail and hospitality settings.
