NCR – Barcode Scanner – 1D – Scanner Only
NCR Parts Accessory Model Overview
Frequently Asked Questions
What imaging technology does the NCR 7879-K151 RealScan 79 use?
The NCR 7879-K151 features a Multiple CMOS Array Imager with multiple diffused PureWhite LED illumination, enabling 360° scanning coverage across all 6 sides with edge-to-edge tower coverage. This advanced imaging technology allows the scanner to read barcodes from multiple angles simultaneously, improving checkout speed and reducing missed scans in high-volume retail environments.
What barcode symbologies does the NCR 7879-K151 support?
The RealScan 79 supports a comprehensive range of barcode formats including UPC/EAN with add-on symbols, Code 128, Code 39, Interleaved 2 of 5, Codabar, GS1 DataBar (RSS) variants, PDF417, and QR Code. This wide symbology support ensures compatibility with virtually all retail and logistics labeling standards, making it ideal for warehouse and point-of-sale applications.
What connectivity options are available on the NCR 7879-K151?
The NCR 7879-K151 offers multiple connectivity options including RS-232, USB (NCR and IBM/POS variants), IBM RS-485, and Ethernet connectivity for networking and security. The scanner also includes auxiliary ports with 4 additional USB Type A connections, EAS interlock ports, and Ethernet/USB for streaming video, providing flexible integration into existing POS and warehouse management systems.
Can the NCR 7879-K151 be upgraded to include weighing capabilities?
Yes, the NCR 7879-K151 can be easily upgraded to a scale in the field. The scanner supports scale capacities ranging from 6/15 kg in 0.002/0.005 kg increments (12/30 lbs in 0.005/0.01 lb increments), with a maximum static weight of 136 kg (300 lbs), and price computing scale options are available for retail applications requiring integrated weighing.
What window materials protect the NCR 7879-K151's scanning lens?
The RealScan 79 features shatter-proof tempered glass for the vertical window and hurricane glass for the lower horizontal window. The horizontal top plate is available in standard EverScan material or optional Sapphire glass, providing durability and optical clarity for high-traffic retail environments.
What are the power requirements for the NCR 7879-K151?
The NCR 7879-K151 requires a 24V dedicated power connection, with an optional external 75W power supply available for installations requiring additional power distribution flexibility. Contact us today to discuss your specific power infrastructure requirements and ensure proper installation at your facility.
