NCR 7603M133 POS Touch Terminal

Part Number: 7603M133
Model: RealPOS XR6

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Processor Manufacturer
Intel
Processor Type
Core i3
Standard Memory
4 GB
Memory Technology
DDR3 SDRAM

Product Description:

  NCR RealPOS XR6 - Intel Core i34 GB DDR3 SDRAM - 120 GB SSD - Windows Embedded POSReady 7

NCR RealPOS XR6 POS Touch Terminal Model Overview

The NCR RealPOS XR6 is the smallest and most powerful point-of-sale (POS) terminal designed for retail environments. Boasting a compact and smart design, this robust unit is built with a die-cast aluminum chassis that ensures durability while conserving valuable checkout space by being up to 70% smaller than traditional options. Equipped with the latest 4th generation Intel® Core™ M processor technology, it provides exceptional performance for fast sales processing. With its user-friendly design and easy serviceability, the RealPOS XR6 enhances the customer checkout experience seamlessly.

Key features
  • Powerful performance with Intel®'s Q87 Express Chipset and 4th generation processors
  • Compact and smart design with versatile mounting options
  • Rugged, die-cast aluminum chassis in a bold black color


Specifications
  • Processor:
    • Intel® Core™ i5-4590T
    • Intel® Core™ i3 - 4350T
    • Intel Celeron™ G1820TE
  • Motherboard: Intel Q87 Express Chipset, NCR DataGuard™ enabled
  • Memory: 4 GB DDR3 memory, expandable up to 16GB
  • Storage Options:
    • 120GB Solid State Drive (SSD)
    • 500GB Hard Disk Drive (HDD)
    • Dual disk drive option available
  • Connectivity:
    • 8 USB ports (4 Powered USB 12V, 1 Powered USB 24V, 2 PC USB 3.0)
    • 4 Serial ports (selectable 0/5/12V)
    • 3 Video interfaces (Display port, HDMI, VGA)
    • 10/100/1000MB (Gigabit) Ethernet LAN
  • Operating Systems: Windows® Embedded POS Ready 7, Windows 7 Professional, SUSE Linux Enterprise for POS, Windows 10 (Future)
  • Product Dimensions: Width: 10" (25.4cm), Depth: 8.9" (22.6cm), Height: 3" (7.6cm)
  • Weight: Terminal with power supply: 8lbs/3.63kg, Terminal only: 6.3lbs/2.86kg
NCR 7603M133 POS Touch Terminal Overview

Big things come in small packages
The NCR RealPOS XR6 is a powerful and flexible point-of-sale (POS) terminal featuring a smart, compact design combined with the ruggedness you need for your retail stores.

Small, but powerful
The RealPOS XR6 is the smallest POS in its class, but don't let its size fool you-it's a powerful workhorse. Up to 70% smaller than traditional POS offerings, the XR6's space-saving design conserves valuable checkout space without sacrificing features and functionality. The XR6 is built to last with a rugged, die-cast aluminum chassis and an innovative cooling system to help it endure the toughest retail environments.

Keep those checkout lines moving
Powered by 4th generation Intel® Core™ processor technology, the RealPOS XR6 delivers exceptional performance to help you ring up those sales quickly and accommodate your future checkout needs. Its smart, retail-centric design features an optimized mix of powered USB and serial interfaces to give you the connectivity your checkouts need while eliminating those extra power bricks.

Keep it simple
We understand how critical it is to have all of your checkouts continuously up and running. That's why we designed the RealPOS XR6 to be quickly and easily serviced. Its EZ-Open hinged chassis gives you convenient access to internal components, and an on-board image recovery button is included to efficiently restore your POS software image.

The bottom line
The NCR RealPOS XR6 is ideal for virtually any retail checkout environment. You can create a customized POS solution by combining it with NCR's extensive family of displays, scanners and other retail peripherals to meet the unique requirements of your stores. With big performance packed in a small terminal, the RealPOS XR6 helps you deliver a superior checkout experience to your customers.

Processor & Chipset
Processor Manufacturer:
Intel
Processor Type:
Core i3
Memory
Standard Memory:
4 GB
Memory Technology:
DDR3 SDRAM
Storage
Solid State Drive Capacity:
120 GB
Network & Communication
Ethernet Technology:
Gigabit Ethernet
Interfaces/Ports
USB:
Yes
Powered USB:
Yes
Network (RJ-45):
Yes
Cash Drawer Port:
Yes
Serial Port:
Yes
Software
Operating System:
Windows Embedded POSReady 7
Physical Characteristics
Color:
Black
Height:
3"
Width:
10"
Depth:
8.9"
Weight (Approximate):
6.30 lb
Item Numbers
UNSPSC: 43211505
