Frequently Asked Questions
What barcode types can the Datalogic GM4500-HC scan?
The GM4500-HC is an omnidirectional 2D area imager that reads all common 1D and 2D barcodes, including Code 39, EAN-13, Data Matrix, PDF417, QR codes, and postal codes plus stacked and composite codes. Its advanced imager technology delivers quick, reliable scanning across general purpose and healthcare applications. We offer this scanner with standard or high-density resolution options to match your specific barcode requirements.
Does the GM4500-HC support wireless connectivity?
Yes, the GM4500-HC-910K10-B model features 910 MHz cordless wireless technology with Datalogic's STAR system, providing maximum flexibility for mobile scanning operations. The scanner also supports Bluetooth wireless technology as an alternative connectivity option. Both wireless solutions include batch mode capability with over 1200 codes stored in memory, allowing workers to scan offline and sync data later.
What is the wireless charging system on the GM4500-HC?
The GM4500-HC features Datalogic's innovative contactless wireless charging system, which enhances reliability and eliminates wear from traditional charging connectors. The included WLC4090-HC-910 base station supports Datalogic's patented 2-position cradle with 'Scan-While-Charging' capability, allowing operators to charge the scanner while actively using it. This design significantly extends the lifespan of the entire solution.
Is the GM4500-HC suitable for healthcare environments?
Yes, the GM4500-HC is specifically designed for healthcare applications with disinfectant-ready enclosures treated with anti-microbial additives (ISO22196 and JISZ 2801 compliant). The scanner includes vibration feedback options ideal for quiet bedside patient care environments, and Datalogic's 'Green Spot' technology provides visual good-read confirmation without audible alerts. We offer this model as part of our healthcare barcode scanner lineup available from barcodesinc.com.
What is the reading range and depth of field for the GM4500-HC?
The GM4500-HC Standard Range model delivers variable reading distances depending on barcode type and size—for example, Code 39 at 10 mils reads from 0.8 to 22.8 inches, while EAN-13 at 13 mils reads up to 27.9 inches. The scanner features advanced motion tolerance optics rated at 35 inches per second and supports reading angles of ±65° pitch and yaw with 360° roll capability. Typical depth of field is determined by symbol length, scan angle, print contrast ratio, and ambient light conditions.
What accessories and configurations are included in the GM4500-HC kit?
The GM4500-HC-910K10-B BPOC (Barcode Point-of-Care) kit includes the scanner, WLC4090-HC-910 wireless charging base station, and USB cable (Part# 90A052278) for complete out-of-box deployment. Additional compatible accessories available from us include the RBP-GM40 removable battery pack for extended operations and the CHR-GM40-WT charging-only base station. Contact us today at barcodesinc.com to configure the right bundle for your warehouse or healthcare facility.
