NCR Orbit HF680 – Barcode Scanner
NCR Parts Accessory Model Overview
Frequently Asked Questions
What barcode types can the NCR Orbit HF680 scanner read?
The NCR Orbit HF680 is a 2D hands-free area-imaging scanner capable of reading both 1D and 2D barcodes, including Code 39, PDF417, Data Matrix, UPC-A, and QR codes. Its megapixel sensor and 1GHz processor enable fast scanning of digital barcodes and even damaged barcodes that other scanners may struggle with.
What is the scanning depth of field for the NCR Orbit HF680?
The Orbit HF680 offers variable depth of field depending on barcode resolution. For example, 13 mil UPC-A barcodes scan from 0–210 mm, while 20 mil Code 39 barcodes scan from 0–300 mm. The scanner supports a minimum resolution of 3 mil for 1D codes and 6.7 mil for 2D codes, with performance varying based on barcode quality and environmental conditions.
How is the NCR Orbit HF680 powered and what are its power requirements?
The scanner connects via USB with a 1.5M USB 5V cable and requires 5 VDC ±0.5V input. During operation, it draws 2.0 W (400 mA @ 5V), and in standby mode consumes only 0.85 W (170 mA @ 5V), making it energy-efficient for continuous retail environments.
What connectivity options does the NCR Orbit HF680 offer?
The Orbit HF680 supports both USB and RS-232 host interfaces, providing flexibility for integration into various POS and retail systems. The included 1.5M USB 5V cable enables straightforward connection to modern checkout terminals and computers.
Can the NCR Orbit HF680 operate in different temperature and humidity conditions?
Yes, the Orbit HF680 is designed for operating temperatures from -10°C to 40°C (14°F to 104°F) and can be stored in temperatures ranging from -40°C to 60°C (-40°F to 140°F). It operates reliably in humidity levels from 0% to 95% RH with no condensation, and is designed to withstand 1-meter drops.
What are the physical dimensions and weight of the NCR Orbit HF680?
The Orbit HF680 measures 85 mm (L) × 88 mm (W) × 139 mm (H) and weighs 278 ±10 grams. Its compact design with tilting scanning head allows operators to comfortably pick up and position the scanner for scanning large, bulky items at various angles.
