Full specifications (PDF)
Connectivity Technology:
Wireless
Motorola VC70N0-F-60VDC-U-R Data Terminal
Part Number:
VC70N0-F-60VDC-U-R
Model:
VC70N0
Motorola VC70N0 Data Terminal Model Overview
The VC70N0 is the right-sized device for all your material-handling vehicles. Its compact design improves visibility and safety while still providing a large high-resolution display for all the information operators need to improve productivity and task accuracy, in almost any lighting condition. The powerful VC70N0 supports traditional Telnet to modern browser-based graphic-rich applications, covering receiving, put-away, replenishment, picking, packing and shipping. You get the flexibility to add the options needed to maximize efficiency - including corded or cordless barcode scanners, keyboards and a variety of voice capabilities.
Motorola VC70N0-F-60VDC-U-R Data Terminal Overview
The VC70N0 is the right-sized device for all your material-handling vehicles. Its compact design improves visibility and safety while still providing a large high-resolution display for all the information operators need to improve productivity and task accuracy, in almost any lighting condition. The powerful VC70N0 supports traditional Telnet to modern browser-based graphic-rich applications, covering receiving, put-away, replenishment, picking, packing and shipping. You get the flexibility to add the options needed to maximize efficiency - including corded or cordless bar code scanners, keyboards and a variety of voice capabilities.
Technical Information
Processor & Chipset
Processor Manufacturer:
Texas Instruments
Processor Speed:
1 GHz
Memory
Standard Memory:
512 MB
Flash Memory:
2 GB
Display & Graphics
Screen Size:
10.4"
Graphics Modes:
XGA
Display Screen Type:
LCD
Touchscreen:
Yes
Display Resolution:
1024 x 768
Network & Communication
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11a/b/g/n
Interfaces/Ports
Network (RJ-45):
Yes
Serial:
Yes
USB:
Yes
CANbus:
Yes
Software
Operating System:
Windows Embedded Compact 7
Physical Characteristics
Width:
8.9"
Depth:
2.4"
Length:
11.5"
Miscellaneous
Certifications & Standards:
- IP 66
- MIL -STD 810G; Method 514.6
- MIL -STD 810G; Method 516.6
- MIL -STD 810G
- IEC 68-2-5
Electrical Safety:
- UL /cUL /IE C/EN 60950-1 Indoor Use
- UL /cUL /IE C/EN 60950-22 Outdoor Use
EMI /RFI:
- FCC Part 15, Class B
- ICES 003 Class B
- EN55022
- EN 301 489-1
- EN 301 489-17
WLAN:
- FCC Part 15.247, 15.407
- RSS-210
- EN 300 328
- EN 301 893
- AS/NZS 4268
Flammability:
- IEC UL 94-VO
Environmentally Friendly:
Yes
Environmental Certification:
- RoHS
- WEEE
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN:
0053926228171
UPC:
053926228171
EAN:
0053926228171
UNSPSC:
43211505
