Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
2D
Barcode Symbology Supported:
1-D / LINEAR CODES:
- UPC/EAN (UPCA/UPCE/UPCE1/EAN-8/EAN-13/ JAN-8/JAN-13 plus supplementals)
- ISBN (Bookland)
- ISSN
- Coupon Code
- Code 39 (Standard, Full ASCII, Trioptic)
- Code 128 (Standard, UCC/EAN-128, ISBT-128 Concatenated)
- Code 93
- Codabar/NW7
- Code 11 (Standard, Matrix 2 of 5)
- MSI Plessey
- I 2 of 5 (Interleaved 2 of 5 / ITF, Discrete 2 of 5, IATA, Chinese 2 of 5)
- GS1 DataBar (Omnidirectional, Truncated, Stacked, Stacked Omnidirectional, Limited, Expanded, Expanded Stacked, Inverse)
- Base 32 (Italian Pharmacode)
PDF417 (and variants):
- PDF417 (Standard, Macro)
- MicroPDF417 (Standard, Macro)
- Composite Codes (CC-A, CC-B, CC-C)
2-D:
- TLC-39
- Aztec (Standard, Inverse)
- MaxiCode, DataMatrix/ECC 200 (Standard, Inverse)
- QR Code (Standard, Inverse, Micro)
Postal:
- U.S. Postnet and Planet
- U.K. Post
- Japan Post
- Australian Post
- Netherlands KIX Code
- Royal Mail 4 State Customer
- UPU FICS 4 State Postal
- USPS 4CB
Light Source:
LED
Image Sensor Type:
Imager
Maximum Scan Resolution:
7.80 mil
Depth of Field:
- 0cm - 12.7cm@5mil - Code 39
- 0cm - 34.3cm@10mil - UPC/EAN
- 0cm - 45.7cm@13mil - UPC/EAN
- 0cm - [email protected] - PDF417
- 0cm - 15.2cm@10mil - Datamatrix
Scan Pattern:
Omni-directional
Scanning Distance:
18"
