Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- UPC/EAN
- UPC/EAN with Supplementals
- Bookland EAN
- ISSN
- UCC Coupon Extended Code
- Code 128
- GS1-128
- ISBT 128
- Code 39
- Code 39 Full ASCII
- Trioptic Code 39
- Code 32
- Code 93
- Code 11
- Matrix 2 of 5
- Interleaved 2 of 5
- Discrete 2 of 5
- Codabar
- MSI
- Chinese 2 of 5
- GS1 DataBar Variants
- Korean 3 of 5
- ISBT Concatenated
- PDF417
- MicroPDF417
- Composite Codes
- TLC-39
- Data Matrix
- Maxicode
- QR Code
- MicroQR
- Aztec
- Han Xin
- Australian Post
- US PLANET
- Royal Mail 4 State Customer
- US POSTNET
- KIX Code (Dutch)
- UK Postal
- Japan Post
- UPU 4 State Postal FICS (Post US4)
- USPS 4 State Postal (Post US3)
Light Source:
LED
Image Sensor Type:
Imager
Maximum Scan Resolution:
100 mil
Depth of Field:
- 0.8" - 4.7"@3mil - Code 39
- 0" - 8.5"@4mil - Code 39
- 0" - 10.0"@5mil - Code 39
- 0" - 15.5"@7.5mil - Code 39
- 0" - 22.4"@13mil - 100% UPC-A
- 0" - 36.0"@20mil - Code 39
- 0" - 47.6"@26mil - 200% UPC-A
- 0" - 175.0"@100mil - Reflective
- 0.8" - 6.2"@5mil - PDF 417
- 0.3" - 8.5"@10mil - Data Matrix
Scan Pattern:
Omni-directional
